2015 High Lumens 100w Led Flood Light Led Flood Light 100w

2015 High Lumens 100w Led Flood Light Led Flood Light 100w thumbnail-1
2015 High Lumens 100w Led Flood Light Led Flood Light 100w photo-1
US$ 40 - 300 MOQ: 10 Packs
Key Specifications
Get Latest Price
LED Light Source:
100w cob led
Input Voltage(V):
85-265v
Lamp Power(W):
110
Contact Supplier Request Quote Chat Now
Pros Light Co., Ltd. (Shenzhen)
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen or HK
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source 100w cob led
Input Voltage(V) 85-265v
Lamp Power(W) 110
Lamp Luminous Flux(lm) 9000
Lamp Luminous Efficiency(lm/w) 110
Color Temperature(CCT) Cool White
Working Temperature(℃) -25, 50
Working Lifetime(Hour) 50000
Lamp Body Material Aluminum
IP Rating IP65
Certification CE, EMC, LVD, UL
Place of Origin Guangdong, China
Brand Name Proslight-flood light
Model Number PL-FWL100W-TG

2015 high lumens 100w led flood light led flood light 100w

2015 high lumens 100w led flood light led flood light 100w



Feature for led floodlight:

>Adjutabe projecting direction

>Instant on/off; No UV flickering

>50% less power consumption than traditional light source

>VDE/UL listed rubber cable with cold-pressed terminal

>Qualified materials i.e. constant current driver from Meanwell and Brightlux Chip

>High power LEDs from Bridgelux

>Built-in cooper heatpipe



 Outdoor led flood light specification:

Item No PL-FWL100W-TG
Power 100watt
Luminous Flux 9000lm
LED Brand Bridgelux LED
LED Qty 1pc
Dimension 309x250x116mm
LED Driver Brand MEANWELL
Power Factor 0.95
Power Efficiency 98%
Housing Material Pure Aluminium+tempered glass+ASA frame
Lamp shell color Black
Correlated Color Temperature Warm white/M 2800K-3000K
Natural White/NW 4000K-4500K
White/W 6000K-7000K
Color Rendering Index M RA>80
NW/W RA>75
Connect wire L Power line
N Null line
G Earth line



2015 high lumens 100w led flood light led flood light 100w

2015 high lumens 100w led flood light led flood light 100w



Step 1: Power must be cut off before installation,it's not allowed to do all this with power on.
Step 2: Put two screws on where required the same size as position A what it's indicated in the diagram.
Step 3: turn up to any beam angle needed by rotating the lamp body.
Step 4:Make connection of Blue with L line, Brown with N line and yellow green wires with Earth Line, turn it on when it's connected properly.



 Applications for outdoor led flood light: 2015 high lumens 100w led flood light led flood light 100w

1. Tunnel, Subway, Underground light;
2. Gym, Sports Stadium flood light;
3. Building, Billboard;
4. Gas Station, Garage lamp flood light;
5. Park, Garden lighting;
6. Workshop, Factoy;
7. Warehouse, Storage;
8. Yard, Square;
9. Road, Highway light;
10. Station, Dock, Deck, Ship, Boat;
11. Aquarium etc.

LED light aging test



2015 high lumens 100w led flood light led flood light 100w



Replacement:





2015 high lumens 100w led flood light led flood light 100w



Package:





Accessories for led flood lighting:

2015 high lumens 100w led flood light led flood light 100w

2015 high lumens 100w led flood light led flood light 100w2015 high lumens 100w led flood light led flood light 100w2015 high lumens 100w led flood light led flood light 100w

Packaging & Shipping

100w led floodlight 50w,outdoor led flood light/rgb led flood light/flood light led/50w led flood light/ip65 led floodlight/led flood lamp/led flood lighting:

4pcs/cartoon,cartoon size:74x44x56cm,gross weight:27.5kg

  2015 high lumens 100w led flood light led flood light 100w





Company Information

Pros Light Co.,Ltd is a well established high-tech firm specialized in production, R&D and marketing of led lighting products.



Our main products are led street light, led floodlight, led explosion-proof light, led high bay light, led panel, led spot light, led tube and so on.



For more information of led floodlight 50w 100w 70w 150w/ led flood light 50w 70w 100w/led floodlighting rgb/outdoor led flood light/led flood lamp/led tunnel light , please feel free to contact us.



Certifications
