Diamond Core Drill Bit Segment
US$ 0.5 - 3
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Hunan, China
Brand Name:
Chenguang
Model Number:
dia25-350
Payment & Shipping
Payment Methods:
Port of Shipment:
any port in China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Hunan, China
Brand Name
Chenguang
Model Number
dia25-350
Type
Power Tool Parts
Specifications
diamond core drill bit segment1.Fast cutting speed
2.Good sharpness
3.Cost-effective,various type
4.Stable performacnce
1.Diamond drill core bit segment
1. Special formula for different cutting request in using diamond drill core bit segment .
2. Various sizes can be chosen in diamond drill core bit segment .
2.Application:
for drilling brick wall, cured reinforced concrete, refractory, asphalt, granite, marble
3.Specification:
Outer Diameter |
Body length | Body Thickness | Segmnet Dimension | Teeth No. | |
| (MM) | Inch | (MM) | (MM) | (MM) | (PCS) |
| 25mm | 1" | 350/400/450 | 1.8 | 12x10x3.0 | 4 |
| 30mm | 1-1/5" | 350/400/450 | 1.8 | 15x10x3.0 | 4 |
| 35mm | 1-3/8" | 350/400/450 | 1.8 | 15x10x3.0 | 4 |
| 40mm | 1-3/5" | 350/400/450 | 1.8 | 24x10x3.5 | 4 |
| 45mm | 1-3/4" | 350/400/450 | 1.8 | 24x10x3.5 | 5 |
| 50mm | 2" | 350/400/450 | 1.8 | 24x10x3.5 | 5 |
| 56mm | 2-1/5" | 350/400/450 | 1.8 | 24x10x3.5 | 6 |
| 60mm | 2 2/5" | 350/400/450 | 1.8 | 24x10x3.5 | 6 |
| 66mm | 2 3/5" | 350/400/450 | 1.8 | 24x10x3.5 | 6 |
| 70mm | 2 3/4" | 350/400/450 | 2 | 24x10x3.5 | 7 |
| 76mm | 3" | 350/400/450 | 2 | 24x10x3.5 | 7 |
| 80mm | 3-3/20" | 350/400/450 | 2 | 24x10x3.5 | 7 |
| 86mm | 3-2/5" | 350/400/450 | 2 | 24x10x3.5 | 8 |
| 90mm | 3-11/20" | 350/400/450 | 2 | 24x10x3.5 | 8 |
| 101mm | 4" | 350/400/450 | 2 | 24x10x3.5 | 9 |
| 107mm | 4-1/5" | 350/400/450 | 2 | 24x10x3.5 | 9 |
| 112mm | 4-2/5" | 350/400/450 | 2 | 24x10x3.5 | 10 |
| 122mm | 4-4/5" | 350/400/450 | 2 | 24x10x3.5 | 10 |
| 132mm | 5-1/5" | 350/400/450 | 2 | 24x10x3.5 | 11 |
| 143mm | 5-5/8" | 350/400/450 | 2 | 24x10x3.5 | 11 |
| 152mm | 6" | 350/400/450 | 2 | 24x10x4.0 | 12 |
| 158mm | 6-1/5" | 350/400/450 | 2.4 | 24x10x4.0 | 12 |
| 161mm | 6-7/20" | 350/400/450 | 2.4 | 24x10x4.0 | 12 |
| 171mm | 6-3/4" | 350/400/450 | 2.4 | 24x10x4.5 | 13 |
| 181mm | 7-1/8" | 350/400/450 | 2.4 | 24x10x4.5 | 14 |
| 200mm | 7-7/8" | 350/400/450 | 2.4 | 24x10x4.5 | 15 |
| 218mm | 8-3/5" | 350/400/450 | 2.7 | 24x10x4.5 | 16 |
| 225mm | 8-7/8" | 350/400/450 | 2.7 | 24x10x4.5 | 16 |
| 250mm | 9-17/20" | 350/400/450 | 2.7 | 24x10x5.0 | 17 |
| 270mm | 10-5/8" | 350/400/450 | 2.7 | 24x10x5.0 | 19 |
| 300mm | 11-4/5" | 350/400/450 | 3 | 24x10x5.0 | 21 |
| 320mm | 12-3/5" | 350/400/450 | 3 | 24x10x5.0 | 23 |
| 350mm | 13-4/5" | 350/400/450 | 3 | 24x10x5.0 | 23 |
4. Pictures:
