Customized Design Drawing Construction Steel Structure Steel Frame Workshop
- 2000 Ton / Tons per Month
- Qingdao Port
- T/T L/C D/P D/A
Product Details
Place of Origin: | Shandong, China | Brand Name: | Weifang Tailai | Model Number: | Steel Structure |
Product Description
Steel structure is a structure which is made from the organized combination of custom-designed structural steel members to meet architecture and engineering requirements of users. Steel structure involves sub-structure or members in a building made from structural steel. These steel structures are widely used in the modern industrial construction, civil construction, public buildings, municipal works and road and bridge projects for its high intensity, light weight, short building time features.
Application:
Steel structure is mainly used for warehouses, workshops, 4S car exhibition centers, shopping mall, aircraft hangers, poultry & pig houses, container houses and so on.
Advantages:
1.Environmental protection: dry construction makes no damage to the construction site environment. There is little noise and dust in the process of steel structure erection because structural steel members are fabricated at the factory.
2.Comfort: respiratory function with which can adjust indoor air humidity.
3.Insulation resistance: sound effect is an important index to evaluate the residential building. Windows adopts hollow glass so sound insulation is good.
4.Shortcut: all dry construction, no environment effects of season and easy installation.
5.Low cost and maintenance: unit price range from USD35 to USD70/square meter FOB according to customer request and requires less maintenance fee than other traditional building methods.
6.Long service life: up to 50 years.
Main parts of the steel structure building and specification:
Main Steel Frame System | |
Main structure | H section steel Q345, alkyd painting, two primary painting, two finish painting. |
Roof purlin | XZ160*60*20*2.5, galvanized |
Wall purlin | XZ160*60*20*2.5, galvanized |
Intensive bolt | Grade 10.9 |
Turn buckle bolt | M20+2, steel Q235, processing |
Anchor bolt | M24, steel Q235, processing |
Ordinary bolt | Galvanized bolt M20 |
Ordinary bolt | Galvanized bolt M12 |
Brace nut | Galvanized bolt M12 |
Bracing System | |
Cross brace | 20 round steel bar Q235, process and painted (alkyd painting) |
Angle brace | L50*5 angle steel Q235, process and painted (alkyd painting) |
Column bracing | φ25 round steel bar Q235, process and painted (alkyd painting) |
Tie bar | φ127*3 steel pipe Q235, process and painted (alkyd painting) |
Batter brace | φ32*2.5, φ12 round steel bar Q235, process and painted (alkyd painting) |
Wall & Roof System | |
Roof panel | Corrugated steel plate or sandwich panel (EPS/fiber glass/rock wool/PU) |
Wall panel | Corrugated steel plate or sandwich panel (EPS/fiber glass/rock wool/PU) |
Edge cover | 0.4mm color plate, angle Alu. |
Fittings & accessories | Nails, glue etc. |
Unpowered ventilator | Diameter 600, stainless steel |
Sky lighting band | 1.2mm FRP, double layer |
Sliding door | sandwich panel door |
Roof drainage system | |
Gutter | 0.8mm color steel plate |
Rainspout pipes | φ160 PVC pipe |
If you have a drawing, please send it to us, then we will provide you the quotation with in two or three days, with the installation instruction.
If not, please send us your project details and your requirements. Then we will design the layout drawing accordingly, free of charge, especially for you. Afterwards, please check and confirm the drawings. If not, we shall get the drawings revised until your final confirmation. Finally, we will provide the final quotation, layout drawing and installation instruction. Also, if you need our engineer on site, or need we send a team of workers, we will discuss and added it in our final quotation.
Project details ---> Drawings and quotation for your project ---> Revised drawings ---> Welcome to visit our factory and inspect our products--->Transaction confirmation with Trade Assurance.
Please fill the table below to us, if you do not have the drawing.
Your location | Country________ State________ City_______ Postal code________ |
Size | Length________meter ;Width________meter; Height________meter |
Storey | Storey number________ |
Wind Load | ________ km/hour |
Snow Load | ________ kn/m² |
Anti-earthquake | ________ magnitude |
Roof Normal Payload | ________ kg/ m² |
Brick wall needed or not | If needed, brick height________ |
Thermal insulation if needed | If needed, EPS panel, PU sandwich panel Glass wool panel, Rock wool panel are optional. |
If needed, normal pre-painted steel tile will be used for your project. | |
Crane if needed | If needed, _____units, max lifting weight____tons; max lifting height _____m |
Storage Cargo condition | If additional requirement for anticorrosive |
1. Steel structure columns and bems will be loaded into 40ft OT container.
2. Sandwich panel, windows, doors and other accessories will be loaded into 40ft HQ container.
3. Steel structure components will be in nude packaging with proper protection.
4. Sandwich panels will be covered with plastic film.
5. Bolts and other accessories will be loaded into wooden boxes.
1. I do not have structure plan of your prefabricated steel structure industrial warehouse with low cost yet, can you design for me?
We would be happy to help you design your prefabricated steel structure industrial warehouse with low cost. Actually designing capability is the divide of the whole industry. Tailai steel design team will make sure you get the most professional, reliable, solid, durable designing plan based on your own situation, and we provide comprehensive support service for steel structure warehouse including design, manufacture, shipping, installation, maintenance and renew or any problems you may encounter when you are using our products.
2. Can I specify the surface color of wall and roof of my prefabricated steel structure industrial warehouse with low cost?
Of course, you can pick up any color you like or by your RAL samples. The images of warehouse with various color and structure format enclosed with are pictures of completed projects sent from our clients; most of the example projects are color-customized by our clients. Not only surface painted color, surface finishing film, but also the padding material of roof panel and wall panel can be changed base on your situation and preference.
3. How is the water-proof property of the prefabricated steel structure industrial warehouse with low cost you produce?
The Roof Panel has been designed to take care of any water leaking problem. Groove located in lap-joint based on the basic principle of hydromechanics could effectively prevent any leakage as well as cold bridges effect. The pre-painted film is also anti-corrosion and water-proof.
Our clients located in west middle Africa and Brazil also have this problem; we reinforced the water-proof system by adding additional roof anti-water plastic board or seam woven polyester fabric, these process can make water leak no longer a problem within 10-15 years even 25 years, and only need very easy step to maintenance.
4. We are planning to build refrigerator storage warehouse, is your product suitable?
For refrigerator building, our clean board is designed for this purpose. Use clean board for wall panel and roof panel system can bring building with extremely good thermal insulation property and water-proofness, and antistatic material makes dust nowhere. We could offer a whole solution for refrigerator industry.
5. Do you accept any quality inspection from a third party before out of factory of the prefabricated steel structure industrial warehouse with low cost?
As mentioned above, we have 360° QC in every step of production, quality is one of the thing makes Tailai steel structure difference with most other steel companies. And you are very welcomed to arrange any third party quality inspection team to our factory, we would be happy to cooperate with them.
6. How can I install these warehouse components together as a building after cargo arrived?
Normally, most clients choose to install the structure frame themselves or ask local technical engineer for further instruction.
If local technical support is not available or cost too much, Tailai Steel Structure could also provide technical support engineer cross over-seas for installation guide even with our installation engineering team.
7. How to maintain my prefabricated steel structure industrial warehouse with low cost years of using?
prefabricated steel structure industrial warehouse with low cost are built for long-time, reliable, steady usage purpose, the maintenance process is easy to operate and complete, most our product can live 10-15 years with minimal maintenance work like gel filled and paint spray. CMCO Steel will keep tracking the usage performance of our products and provide maintenance instruction for our clients.
8. If I need to renew my old warehouse, can I use your help?
If your warehouse was not built with the products imported from our company, we may need the blue-print or design plan of your warehouse, so we could supply proper components or modules to fit your structure system.
For clients importing from our company, we only need to know warehouse overall situation, the damage part location and damaged condition, so we could provide a more detailed integrated renew plan for your warehouse.
Contact Us:
Michael Meng (Overseas Affairs Director)
Tailai Steel Structure Engineering Co.,Ltd.
Factory Add: No.3430 Huangshan Rd, Linqu County, Shandong Province, P.R. China
Overseas Affairs Office Add: Blk 3#2204, Seaview Mansion, No.107 Shandong Rd, Qingdao, P.R. China.
Tel: +86-532-67776932Fax: +86-532-67776931
Cellphone: +86-13256874362
Skype: michealmeng87 WhatsApp: +86-15318790887
Website: http://wftailai.en.china.cn
