Home > Lights & Lighting > Outdoor Lighting > Street Light > 1W 8mm Straw Hat LED, DIP Type,white Color,120degree,120mA Forward Current;60-70lm
1W 8mm Straw Hat LED, DIP Type,white Color,120degree,120mA Forward Current;60-70lm
US$ 0.65 - 0.69
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
RITA
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
0.5W 8mm Straw Hat LED, DIP Type,green Color,120degree,120mA Forward CurrentUS$ 0.42 - 0.43MOQ: 100 Pieces -
0.5W 8mm Straw Hat LED, DIP Type,blue Color,120degree,120mA Forward CurrentUS$ 0.36 - 0.38MOQ: 100 Pieces
-
0.5W 8mm Straw Hat LED, DIP Type,yellow Color,120degree,120mA Forward CurrentUS$ 0.37 - 0.39MOQ: 100 Pieces
-
0.5W 8mm Straw Hat LED, DIP Type,red Color,120degree,120mA Forward CurrentUS$ 0.37 - 0.39MOQ: 100 Pieces
-
0.5W 8mm Straw Hat LED, DIP Type,warm White Color,120degree,120mA Forward Current,30-40lmUS$ 0.34 - 0.36MOQ: 100 Pieces
Place of Origin
Guangdong, China
Brand Name
RITA
Specifications
1W 8mm straw hat LED, DIP type,white color,120degree,350mA forward current;60-70lm| Electrical / Optical Characteristics at TA=25°C | ||||||
| Parameter | Symbol | Min. | Typ. | Max. | Unit | Test Condition |
| Luminous Intensity | Φ | 60 | 65 | 70 | lm | IF = 350mA |
| Viewing Angle | 2θ1/2 | 110 | 115 | 120 | deg | IF = 350mA |
| Dominant Wavelength | Tc | 6000 | 6500 | 7000 | K | IF = 350mA |
| Spectral Line Half-Width | λD | nm | IF = 350mA | |||
| Forward Voltage | VF | 3.0 | 3.3 | 3.6 | V | IF = 350mA |
| Reverse Current | IR | 10 | μA | VR = 5V | ||
| Absolute Maximum Ratings at TA=25°C | ||||||
| Parameter | Maximum Rating | |||||
| Power Dissipation | 1W | |||||
| Peak Forward Current (1/10 Duty Cycle, 0.1ms Pulse Width) |
700mA | |||||
| Continuous Forward Current | 350mA | |||||
| Reverse Voltage | 5V | |||||
| Operating Temperature Range | -40°C to + 55°C | |||||
| Storage Temperature Range | -40°C to + 100°C | |||||
| Lead Soldering Temperature [1.6mm(.063") From Body] |
260°C for 5 Seconds | |||||
