All Welded Wire Wrapped Johnson Screen

Name: All Welded Wire Wrapped Johnson Screen
Brand: guangxing
SKU: 125339203

US$ 10 - 16 MOQ: 50 Meters

Key Specifications

Place of Origin:

Hebei, China

Brand Name:

guangxing

Model Number:

gx325

Hengshui Guangxing Screens Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

xingang

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hebei, China

Brand Name guangxing

Model Number gx325

Usage Liquid Filter

Type Filter Cylinder

Material Metal

Hole Shape Round

Filter Rating 90%

Thickness 6mm

Length 5800mm

Width 325mm

The welded continuous slot wedge wire screens are made up of rods and wire.

The rod can be round wire, triangular wire or trapezoid wire. The wire is triangular wire (V-shaped wire).

Water well screens have a structure and high open area, as well as accurate slot dimension.

At the same time, water well screens have heat-resisting, anti-corrosive, good machine capability, last long,

safety and reliability and so on characteristics. It can be used in many kinds of medium filtering.

Specification (wedge wire):	Width(mm): 1.50 1.80 2.30 3.00 3.30 3.70 Height(mm): 2.20 2.50 2.70 3.60 4.30 4.70 5.60 6.30 7.00
Specification (support rod):	Width(mm): 2.30 3.00 3.30 3.70 Height(mm): 2.70 3.60 4.70 5.60 6.30 Round: From 2.50mm to 6.0mm
Note: other specifications available as per request
Slot size	0.10, 0.15, 0.20, 0.25, 0.30…… 6.00mm also achieved upon request.
Material:	galvanized low carton (LCG), stainless steel (304,316 etc.)
Length	up to 6 meters.
Diameter	from 25mm to 1200mm.
End connection	Plain beveled ends, flanged or threaded couplings
