Help CenterFlow From Out to in Rotary Water Filter Screen
Related Products
-
Screw Press Separator Solid Liquid Separation Pig DungUS$ 10 - 50MOQ: 30 Meters -
Wedge Wire Cylinder With Stainless Steel 304 / 316LUS$ 10 - 50MOQ: 30 Meters
-
Stainless Steel Cylinder FilterUS$ 10 - 50MOQ: 30 Meters
-
Wedge Wire Cylinders for Liquid Solids SeparationUS$ 10 - 50MOQ: 30 Meters
-
A62 Wedge Wire Screen Sugar Drum ScreenUS$ 30 - 200MOQ: 1 Piece
The rotary drum screen is a mechanical selfcleaning device that was developed to meet the
growing need and demand for an efficient and economical method of removing suspended solids
from mixed liquid streams. The continuous and selfcleaning effect of the rotating screens makes
it possible to use higher flow capacities than those of any other type of screen thus resulting
in substantial savings with respect to both investment and maintenance.
In typical feed situations, the feed is pumped onto the inside of the Trommel Drum, which allows
the liquid and smaller fibres or solids to pass through the screen. The oversized fibres or solids
move across the wedge wire surface to the discharge end of the drum. Trommel Drums can be
manufactured in ASTM304 stainless steels or ASTM316 stainless steel.
Advantages of the rotating Trommel Screen are that large flows can be pumped over a range of
screen drum aperture sizes. The screen surface can also be cleaned as the screen drum rotates
presenting a clean surface to the incoming feed.
In the sugar industry rotating Cush Cush Screens are widely used for the separation of sugar
juice from cane fibre. Depending on the industry, flow rate, and material to be separated,
Trommel/Cush Cush Screens can be manufactured in a large range of diameters, lengths,
apertures and wedge wires. The rotating Trommel Drum is used for separating solids from
liquids or solids from solids in dry feed applications.
Model |
Mixed Juice Capacity (t/hr) |
Drum Diameter (mm) |
Drum Length (mm) |
Drive (KW) |
Feed (inlet) Size |
Discharge (outlet) Size |
Approx. Mass (kg) |
WT610 |
40 |
600 |
1000 |
1.5 |
DN100 |
DN150 |
535 |
WT615 |
73 |
600 |
1500 |
1.5 |
DN100 |
DN150 |
650 |
WT1015 |
99 |
1000 |
1500 |
2.5 |
DN150 |
DN200 |
1050 |
WT1018 |
132 |
1000 |
1800 |
2.5 |
DN150 |
DN200 |
1170 |
WT1518 |
165 |
1500 |
1800 |
4.0 |
DN200 |
DN250 |
1775 |
WT1521 |
214 |
1500 |
2100 |
4.0 |
DN250 |
DN300 |
1940 |
WT1524 |
264 |
1500 |
1400 |
5.5 |
DN250 |
DN300 |
2130 |
WT1824 |
277 |
1800 |
1400 |
5.5 |
DN300 |
DN350 |
3670 |
WT1830 |
396 |
1800 |
3000 |
7.5 |
DN300 |
DN350 |
3040 |
WT1836 |
515 |
1800 |
3600 |
7.5 |
DN350 |
DN400 |
3425 |
WT2136 |
554 |
2100 |
3600 |
11.0 |
DN400 |
DN450 |
4125 |
WT2142 |
693 |
2100 |
4200 |
15.0 |
DN400 |
DN450 |
4575 |
WT2148 |
831 |
2100 |
4800 |
15.0 |
DN450 |
DN500 |
5110 |
Hengshui guangxing screens co.,ltd founded in 2010,is a major manufacturer and supplier of vee wire welded products for professional end-users in the world.It is equipped with modern machines and latest technology for the manufacture of high quality welded wedge wire screens in various shapes and size .We have been recongnized for our excellence in customer solutions creativity flexibility and no nonsense mentality coupled with short delivery time and competitive price.We keep the quality according to the ISO 9001:2008 standard to let the customers satisfy.High quality and competitive price and delivering on time is our aim.We believe that we will contribute to world prosperity by establishing bridges between our country and the global world.If you have interested in our wedge wire prodducts,please contact us.
