Help Center8" 5/8 Diameter Stainless Steel Rod Base Screen
Related Products
-
SS304 Rod Based Screen for Water TreatmentUS$ 10 - 100MOQ: 10 Meters -
Continuous Slot Rod Base Screen ManufacturerUS$ 10 - 100MOQ: 10 Meters
-
V Wire Rod Based Screen/wedge Wire ScreenUS$ 10 - 100MOQ: 10 Meters
-
Rod Base Wire Wrapped ScreenUS$ 10 - 100MOQ: 10 Meters
-
Wire Wrapped Rod Base John Type Well ScreenUS$ 10 - 100MOQ: 10 Meters
Guangxing is a professional manufacturer of rod based screen in China. Rod based screen provide more open area, these non-clogging well screens have a tight slot tolerance, effective sand control and a lower entrance velocity.
Advantages:
Stop sand production
Avoid pump damage
Improve well efficiency
Improve pumping efficiency
Maximize water flow rate into the well
Reduce well maintenance
Increase well life
Specifications:
NB: 1.5" 2" 3" 4" 6" 8" 10" 12" 14" 16"
Slot (mm) : 0.15 0.25 0.5 0.75 1.0 1.5 2.0 3.0
Length: 3m & 6m
Grades: Different grades suitable for tube well depths up to 300ft, 600ft, 900ft and 1500ft
Material: Low carbon galvanized (LCG ) and stainless steel (SS304 SS316)
End connection: Plain beveled ends for butt welding or threaded
Send Inquiry to This Supplier
