Johnson Screen Stainless Steel Wedge Wire Well Screen

Name: Johnson Screen Stainless Steel Wedge Wire Well Screen
Brand: guangxing
SKU: 125337909

US$ 1 - 11 MOQ: 100 Meters

Key Specifications

Place of Origin:

Hebei, China

Brand Name:

guangxing

Model Number:

A1..........A50

Hengshui Guangxing Screens Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin Port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hebei, China

Brand Name guangxing

Model Number A1..........A50

Usage Liquid Filter

Type Filter Cylinder

Material Other, stainless steel

Hole Shape Other, continuous slot

Filter Rating 25%

Thickness 8mm

Length 6m

Product Description

Johnson screen /water well screen filter/ waterscreen

Wire wrapped Well Screen
Specification (Profile wire):		Width(mm): 1.50 1.80 2.30 3.00 3.30 3.70 Height(mm): 2.20 2.50 2.70 3.60 4.30 4.70 5.60 6.30 7.00
Specification (support rods):		Width(mm): 2.30 3.00 3.30 3.70 Height(mm): 2.70 3.60 4.70 5.60 6.30 Round: From 2.50mm to 6.5mm
Note: other wires and rods available upon request
Slot size	0.10, 0.15, 0.20, 0.25, 0.30…… 6.00mm also achieved upon request.
Material:	Low carton, low carton galvanized steel (LCG), stainless steel (304,316 etc.)
Length	2.9 meters,3 meters,5.8 meters,6 meters.
Diameter	1 1/2",2",2 1/2",3",3 1/2",4",6",7",8",9 5/8",10",12",133/8",14",16"
Screen end	Plain beveled ends for butt welding or threaded
Other sizes available on request .Deep well construction specifications available on question. Well depths :100 m, 200 m, 350 m & 600 m.
Advantage	Reduce energy consumption and increase water flow. Reduce erosion of entry surfaces and increase well life. Allow a uniform and efficient well development. Reduce significantly potential pump damage and subsequent maintenance costs.
