It’s a type of well screen with vertical slots that are formed by protruding "bridges” that are pushed outward from the well casing. The sand and gravel can not easily block the slot because of the special bridge design. It has great mechanical strength and water entering capacity. Meanwhile, it use steel punching technology and rolled in many ways, so it is light, cheap and easily operating.
We use CNC to punch, so the slot can change as your requirements. In order to give customers more convenience, we can offer any diameter screens. We also offer galvanized ones to prolong the operational life.
Advantages
1.High strength through resistance to twisting, compressive, and tensile forces.
2. A smooth bore that does not impede the passage of probes, tools, etc.
3. The special structure of the slot makes it difficult for particles to get stuck in the slot, thus bettering its discharge capacity.
4.The special bridge slot of screens helps improving their mechanic strength.
5. Application of Anticorrosive coasting will prolong the span life of wells.
6. Slots and the diameter of bridge slot screens can be custom made to satisfy your needs.
7. Convenient to operate owing to various connecting methods between screens.
1. Continuous slot wire wrap screen
2. Bridge slotted well screen
3. Pipe base screen
4. Prepacked well screen
5. API casing pipe
6. Stainless steel pipe
7. Perforated pipe
8. Slot liner
9. Centralizer
10.Other water well related accessories
Guangxing Screens Company is known world-wide as a manufacturer of high quality stainless steel wedge wire screens including well screen, filter candles, wedge wire flat panel, sieve bend screen and so on. And we provide screening solutions to almost every industry, including:
Water & oil well,
Food & Beverage Screens,
Pharmaceutical & Biological industries,
Refining & Petrochemical,
Water Treatment & Liquid / Solids Separation,
Mineral & Aggregate Processing,
Pulp & Paper Screens.
Through strict quality control and many years of accumulation of experience, we provide customers with reliable products. According to customer requirements, our engineers will design the best product for the customer, not only can increase your efficiency, but also can reduce your purchase cost. We can also be customized according to customer's requirements for processing.
our company took the lead through the ISO 9001:2008 quality management system certification. Through the strict quality management, our products not only meet the needs of customers, but also go beyond the existing industry standard, which provide a solid foundation for us to enter the international market. At present, our products have been exported to Asia, Europe, the Americas, Africa, 35 countries and regions,we are waiting the cooperation with your esteemed company.
