we supply 5-100m3 lpg tank, lpg storage tank, lpg transport tank, lpg tanker trailers, propane transport trailers for sale, propane tanker trailers for sale
following parameters of 100M3 tank lpg storage tanks, 100m3 pressure vessel lpg tank, 100m3 gas storage tank, 100M3 lpg storage tank, 100M3 lpg tanker is just for your reference, we aslo do customized products. special requirements, just call me directly,
Technical specification |
parameters |
Subject |
parameters |
|
|||
tank |
Item Number |
CLG3100-100 LPG tanker 100m3 gas storage tank, 100M3 lpg storage tank, 100M3 lpg tanker, 100m3 pressure vessel lpg tank, 100M3 tank lpg storage tanks |
Liquid Indictor |
Model |
UHZ-518C14 |
|
|
Overall dimensions(mm) |
13866*3132*3722 |
Version |
Magnetic |
|
|||
Net weight(Kg) |
20410 |
Normal pressure |
2.5Mpa |
|
|||
Vessel type |
III |
Scope of testing |
50-2300mm |
|
|||
Designing pressure |
1.77Mpa |
Precision |
2.5 |
|
|||
Working pressure |
1.61Mpa |
Safety Valve |
Model |
A42F-2.5-80 |
|
||
Designing temperature |
-19~50°C |
Version |
Built-in |
|
|||
Filling Medium |
Propane |
Normal pressure |
2.5 Mpa |
|
|||
Corrosion margin |
1.0mm |
Normal diameter |
DN80 |
|
|||
Volume |
100CBM(100000L) |
Opening pressure |
1.68-1.76 Mpa |
|
|||
Heat treatment |
bulk |
Re-seating pressure |
≥80% of opening pressure |
|
|||
Filling factor |
420kg/m3 |
Handling System |
Normal Diameter |
Feed pip |
DN80 |
||
Material |
Q345R |
Drain pip |
DN80 |
||||
Hydraulic test pressure |
2.22 Mpa |
Admission port |
DN50 |
||||
Gas tight test pressure |
1.77 Mpa |
Sewage outfall port |
DN80 |
||||
Cylinder thickness |
16mm |
Vent nozzle port |
DN80 |
||||
Head thickness |
18mm |
stand |
GB150-1998<steel pressure vessels> |
||||
Service time |
20 years |
Safety regulation of pressure vessels |
|||||
|
Accessory |
Safety valve, magnetic flap liquid level gauge, pressure gauge, thermometer, cut-off valves, etc. |
|||||
