nuked with wax and roro-ship to every port
chengli special automobile co., ltd
56m3 lpg tank semi trailer
Item |
Unit |
Parameter |
|
Product name |
|
3 axle 56m3 semi-trailer |
|
Practical capacity |
M3 |
56 |
|
Gross weight |
kg |
39000 |
|
Curb weight |
15480 |
||
rated loading capacity |
23520 |
||
Overall dimension |
mm |
12700×2500×3975 |
|
Axle |
3 |
||
Wheelbase |
6865+1310+1310 |
||
Tread |
Front tread |
- |
|
Rear tread |
1840/1840/1840 |
||
Front/rear suspension |
mm |
-/1550 |
|
Leaf spring |
|
-7/7/7 |
|
Fifth wheel max loading |
kg |
16000 |
|
Tyre specification |
|
12R22.5 |
|
Exclusive configuration |
Tank material |
Q345R |
|
Standard configuration |
12T BPW axle, safety valve, single fluid two valve box. hydraulic legs, traction pin ,liquid Indicator, pressure gauge, temperature gage, emergency cut-off valve, valve box, fire suppression bottle, spark hider cover, anti static grounding tape, protective guard, tyre protective shield. set up LPG Pump and flowmeter |
||
Other |
Filling Medium; propane: design pressure 1.77Mpa,design temperature 50°C,filling ratio:0.42t/m3,corrosion allowance:1mm;dimension of tank:12850×2496mm . |
||
Standard configuration |
GB150-19989(Steel pressure vessels),Supervision regulation on safety technology for pressure vessel, Supervision regulation on safety technology for Liquefy gas tank truck. |
||
ngli Special Automobile Co., Ltd is a professional manufacturer of all kinds of special truck and trailer as well as other special equipment. LPG tank is our most advantage key products which rank Top 5 in China, excellent engineers and high-grade production equipment as well as stricted quality control system can ensure all the tank from us run very well with 10-20 years use life.
More information of lpg truck, lpg tank truck, liquid petrol gas tank truck, please feel free to contact with Ms. Bella Li. We will customize the truck according to your requirement. sincerely welcome you to visit our factory and provide your precious suggestion for us!
