4x2 5cbm high pressure cleaning truck
vacuum sewage suction and jetting truck
Product Parameters
4x2 5cbm high pressure cleaning truck vacuum sewage suction and jetting truck
CHASSIS | |||
Cabin | LHD,3 passengers with air-conditioner | ||
Overall Dimension | 7210x2240x2600mm | ||
Gross Vehicle Weight | 8275kg | ||
Curb Weight | 5200kg | ||
Loading Weight | 2880Kg | ||
Wheel Base | 3800mm | ||
Approach/Departure Angle | 24/10 degree | ||
Engine | CY4102; watering cooling, four stroke, 4 cylinder in line; Euro III | ||
Engine horsepower | 124HP | ||
Displacement | 3,856 L(Diesel) | ||
Max Driving Speed | 99km/h | ||
Fuel Tank | 120L | ||
Tire | 7.50-16 (6 pieces + 1 spare) | ||
TANK BODY | |||
Water Tank | Capacity | 2.74CBM | |
Dimension | 2100*1400mm(Length*Diameter) | ||
Material | Q235 high tension steel | ||
Thickness | 4mm | ||
Vacuum Tank | Capacity | 2.94CBM | |
Dimension | 2000*1400mm(Length*Diameter) | ||
Material | Q235 high tension steel | ||
Thickness | 6mm | ||
PUMP | |||
Vacuum Suction Pump | Model | SK-6 | |
Vertical Suction Range | 9~10M | ||
Flow Rate | 1.5m³/min | ||
Rubber tube | 7M | ||
Adequate Vacuum, Strong suction, Stable Working, Easy Operation and Maintenance | |||
Plunger High Pressure Pump | Model | HTT(Italian brand) | |
Flow Rate | 125L/min | ||
Pressure | 16Mbar | ||
Laminated steel tube | 60M | ||
Cleaning Applicator | 10nos with different pushing forces for pipelines cleaning and dredging | ||
4x2 5cbm high pressure cleaning truck vacuum sewage suction and jetting truck is mainly used in the septic tank, gutter, sewer, and other environments that need cleaning.
The watering cart, garbage truck and the Fecal Suction Truck are called as the Three Sanitation Truck together.
*The sanitation department of the government would like to use the Fecal Suction Truck for abstracting and transporting other excrement and polluted water. It has been widely used in various industrial districts and also the municipal sanitation department, residential district and schools.
4x2 5cbm high pressure cleaning truck vacuum sewage suction and jetting truck
