Help CenterDirect Factory Light Weight 40CBM Fuel Gasoline Diesel Crude Oil or Chemical Liquid Tank Semi Truck Trailer
Related Products
-
New Design Chemical Semi Trailer, 45000L Chemical Trailer,chemical Industrial Liquid Tank Tanker Semi Trailer,US$ 29,500 - 35,600MOQ: 1 Set -
China Low Price Chemical Tanker Truck,HCl Chemical Fuel Tank Truck ,Carbon Steel 3axles Oil or Chemical Tank TonUS$ 29,500 - 35,600MOQ: 1 Set
-
Low Price Chemical Tanker Truck,HCl Chemical Fuel Tank Truck ,Carbon Steel 3axles Oil or Chemical Tank TonUS$ 29,500 - 35,600MOQ: 1 Set
-
China Direct Factory Chemical Tank Truck,high Quality Fuel Trailer,3axles Chemical Transportation TrailerUS$ 29,500 - 35,600MOQ: 1 Set
-
DTA 2/3 Axle Plastic- Lined Steel Chemical Lisemi-trailer for HCquid Tank Semi Trailer, NaOH ,NaCIO H2SO4 EtcUS$ 29,500 - 35,600MOQ: 1 Set
2 axle Chemical liquid tank trailer
Main Dimensions |
| |||
Overall dimension(mm) | 11000×2500×3800 |
| ||
Gross weight(KGS) | 40000 |
| ||
Pay load (KGS) | 3200 |
| ||
Filling medium | Chemical liquid |
| ||
Loading Capacity | 38.1m3 |
| ||
Tank Body | ||||
Total Volume(m3) | 38.1CBM |
| ||
Tanker Body Material | 6mm Carbon Steel outside, 16MM thicnkness PE tank inside |
| ||
End plate | 6mm Carbon Steel outside, 16MM thicnkness PE tank inside |
| ||
Lifting Ladder | IncludingTop walkway and backside Aluminum material |
| ||
Manhole cover | 2 sets with 2 breather valves. |
| ||
Bottom Valve | 1 set |
| ||
Discharging valve | 1 set |
| ||
Discharging Pipe | 4”rubber hose, 2 pc, 6m long |
| ||
trailer | ||||
Axle | 3 axles |
| ||
FUWA 13 Ton |
| |||
Wheel base(mm) | 5700+1310+1310 |
| ||
Rear overhang(mm) | 1500 |
| ||
Departure angle | 18° |
| ||
Landing Gear | C200,Two-speed, manual operating, heavy duty landing gear |
| ||
Protective material | Q235 Carbon Steel |
| ||
King Pin | JOST brand 2” bolt-in king pin |
| ||
Suspension | leaf-spring suspension |
| ||
Tire | 11R22.5, 13pcs(one spare ) |
| ||
Equipment | Material: 6mm carbon steel outside. 16MM thicnkness PE tank inside End Cover and Baffles,One compartment with several inner baffles to reinforce the tank strength and prevent longitudinal surge during move. Three compartments, without any connection. And make a trap door on the top of each compartment .Each compartment have security valve and evacuation valve. With 80mm DIAMETER flexible pipe With anticorrosion paint outside the tank to avoid rust With a allowed temperature in technical specification Maximum temperature resistance of the tank≤60° |
| ||
Delivery Time | 40 working days |
| ||
—ChengLi Special Automobile Co.,LTD
Company Profile
Our company has solid technology, flawless inspection,advanced equipments, reliant quality and flexible modes of operation. What’s more, it has roundly passed the ISO9001-2000 and the 3C(China Compulsory Certification).
Our leading varieties include more than 300 types of trucks such as Water truck,Fecal sucktion truck,Garbage truck,Refuse compactor,Sewage sucktion truck,Fuel tank,High-altitude operation truck,Truck with crane,Dump truck,Instructional truck,Van truck, Semi-trailer,Fire engine,Spares,Refrigerator truck,Water wagon,Tractor, High-altitude water truck,Bulk cement truck,Chemical liquid truck,Concrete mixer truck,ect.
Chengli Special automobile Co., Ltd also provide products as follows:
1. LPG Tank Truck Trailer/ Fuel Tanker Truck
2. Water truck / Water Tank Truck / Water Sprinkler Truck/Water Tanker
3. Truck with crane / Truck mounted crane
4. Dump Truck / Tipper Truck/Side Tipper/End Tipper
5. Fire Fighting Truck / Fire Truck / Fire Vehicle
6. Concrete Mixer Truck
7. Van truck / Blasting equipment transporter/ Refrigerated truck
8. Fecal suction truck / Sewage suction truck,
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck,sealed garbage truc
12. Tractor
13. High Pressure Cleaning Truck
14. Sweeper Truck
15. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )
Scale of The Factory
After Sales Service
One year guarantee about three key parts(axle, engine, transmission).Other spare parts could be supplied by cost price.
Group Photo with Clients
The Relevant Certificates
Cooperation Partners
NAME CARD
Sale Manager: Kitty Zhen
Tel/Fax : 00862783796298
Cell:0086-13872880590/13349909442
Website: truckcl.en.china.cn
we sincerely welcome you to visit our factory and provide your precious suggestion for us!
