DP-N6 Series Cement Mortar Sprayers Similar To Putzmeister S5
- NINGBO OR SHANGHAI
- T/T Credit Card
You May Like
Product Details
| Place of Origin | China | Brand Name | DP-N6 Series Cement Mortar Sprayers | |
| Model Number | DP-N6 Series Cement Mortar Sprayers | Condition | New | |
| After-sales Service Provided | Overseas service center available |
Product Description
Specifications
DP-N6 Series Cement Mortar Sprayers Similar To Putzmeister S5,Pump Delivery Capacity: 50L/min ( N6M 40L/MIN)DP-N6 Series Cement Mortar Sprayers Similar To Putzmeister S5
DP-N6 Cement Mortar Spraying Machine ( without MIXER, without COMPRESSOR )
DP-N6M Mixing Mortar-Spraying Machine (with MIXER, without COMPRESSOR )
DP-N6MC cement mortar sprayer (with MIXER, with Combined German KOELLMANN COMPRESSOR )
DP-N6 series Cement Mortar Sprayers are newly designed, economical and practical,durable and high efficiency for spraying cement mortar. Very similar to Putzmeister S5 machine.
Applications:
Specially designed for spray cement mortar, widely applied for construction projects like
secondary grouting for the channels, cement mortar grouting for slope geotechnical
engineering, prestressing duct grouting, water curtain consolidation grouting, void
grouting for soft foundation and concrete pavement slab bottom, and interior/
exterior wall painting, etc.
features:
1. Output volume adjustable (lower/high speed)
2. Equipped with vibration screen.
3. With remote control function.
4. With durable screw pump.
5. Control box: the core of the machine, to drive the motor, air & water pump.
6. Safety cover & quick unpack gear & material hopper: the material can be unpack
by the gear on the net cover, and be even poured into the tank.
7. Quick snap: easy to fix the material hopper and the cart.
8. 5.5KW motor & retarder: to drive the twister for material transportation.
9. Stirrer tank: quick and even mixing material.
10. Water inlet: lead water into the machine from outside.
11. Spinning Form Twister & Screw Pump: the material will be transport to the outlet by
the screw pump after the quick and even mixing by twister.
12. Pressure controller: to adjust the pressure of the mortar pipe to avoid the suddenness
13. Mortar pipe connector: very easy to connect with the machine.
The model of DP-N6 series Cement Mortar Sprayers as follows:
Technical Data:
Voltage/Frequency: 380V/50Hz
Motor Power: 4.5/5.5KW two level adjustable, variable speed (lower/high)
Pump Delivery Capacity: 50L/min ( N6M 40L/MIN)
Hopper Volume: 100L
Standard tip size: 14mm*2pcs, 16mm*2pcs
Working Pressure: 30bar
Delivery Height:1-30m
Delivery Distance: 1-60m
Cement Mortar Size: <6mm
Spraying thickness: 2-3cm
(N6M mixing machine capacity: 120L)
(N6M Mixing speed: 52r/min)
G.W.: 290kgs ( N6M 430KGS)
Overall Demension: 214×75×82cm (N6M 235*85*130CM)
Standard Accessories:
Φ32mm*10m mortar pipe 1pc
Φ8mm*20m vent pipe 1pc
Spray gun 1pc
Repair kit 1set
Tip sizes available: 8 / 10 / 12 / 14 / 16 / 20mm.
8 & 10mm: mainly used for fire protection mortar and thin mortar.
12 / 14 / 16 / 20: used for normal mortar spraying.
DP-N6 series Cement Mortar Sprayers are newly designed, economical and practical,durable and high efficiency for spraying cement mortar. Very similar to Putzmeister S5 machine.
DP-N6 ( without MIXER, without COMPRESSOR, same as Putzmeister S5 )
DP-N6M (with MIXER, without COMPRESSOR, same as Putzmeister S5 EV )
DP-N6C (without MIXER, with Combined German KOELLMANN COMPRESSOR or Separate Chinese Compressor)
DP-N6MC (with MIXER, with Combined German KOELLMANN COMPRESSOR or Separate Chinese Compressor )
Applications:
Specially designed for spray cement mortar, widely applied for construction projects like
secondary grouting for the channels, cement mortar grouting for slope geotechnical
engineering, prestressing duct grouting, water curtain consolidation grouting, void
grouting for soft foundation and concrete pavement slab bottom, and interior/
exterior wall painting, etc.
features:
1. Output volume adjustable (lower/high speed)
2. Equipped with vibration screen.
3. With remote control function.
4. With durable screw pump.
5. Control box: the core of the machine, to drive the motor, air & water pump.
6. Safety cover & quick unpack gear & material hopper: the material can be unpack
by the gear on the net cover, and be even poured into the tank.
7. Quick snap: easy to fix the material hopper and the cart.
8. 5.5KW motor & retarder: to drive the twister for material transportation.
9. Stirrer tank: quick and even mixing material.
10. Water inlet: lead water into the machine from outside.
11. Spinning Form Twister & Screw Pump: the material will be transport to the outlet by
the screw pump after the quick and even mixing by twister.
12. Pressure controller: to adjust the pressure of the mortar pipe to avoid the suddenness
13. Mortar pipe connector: very easy to connect with the machine.
The model of DP-N6 series Cement Mortar Sprayers as follows:
Technical Data:
Voltage/Frequency: 380V/50Hz
Motor Power: 4.5/5.5KW two level adjustable, variable speed (lower/high)
Pump Delivery Capacity: 50L/min ( N6M 40L/MIN)
Hopper Volume: 100L
Standard tip size: 14mm*2pcs, 16mm*2pcs
Working Pressure: 30bar
Delivery Height:1-30m
Delivery Distance: 1-60m
Cement Mortar Size: <6mm
Spraying thickness: 2-3cm
(N6M mixing machine capacity: 120L)
(N6M Mixing speed: 52r/min)
G.W.: 290kgs ( N6M 430KGS)
Overall Demension: 214×75×82cm (N6M 235*85*130CM)
Standard Accessories:
Φ32mm*10m mortar pipe 1pc
Φ8mm*20m vent pipe 1pc
Spray gun 1pc
Repair kit 1set
Tip sizes available: 8 / 10 / 12 / 14 / 16 / 20mm.
8 & 10mm: mainly used for fire protection mortar and thin mortar.
12 / 14 / 16 / 20: used for normal mortar spraying.
DP-N6 series Cement Mortar Sprayers are newly designed, economical and practical,durable and high efficiency for spraying cement mortar. Very similar to Putzmeister S5 machine.
DP-N6 ( without MIXER, without COMPRESSOR, same as Putzmeister S5 )
DP-N6M (with MIXER, without COMPRESSOR, same as Putzmeister S5 EV )
DP-N6C (without MIXER, with Combined German KOELLMANN COMPRESSOR or Separate Chinese Compressor)
DP-N6MC (with MIXER, with Combined German KOELLMANN COMPRESSOR or Separate Chinese Compressor )
Applications:
Specially designed for spray cement mortar, widely applied for construction projects like
secondary grouting for the channels, cement mortar grouting for slope geotechnical
engineering, prestressing duct grouting, water curtain consolidation grouting, void
grouting for soft foundation and concrete pavement slab bottom, and interior/
exterior wall painting, etc.
features:
1. Output volume adjustable (lower/high speed)
2. Equipped with vibration screen.
3. With remote control function.
4. With durable screw pump.
5. Control box: the core of the machine, to drive the motor, air & water pump.
6. Safety cover & quick unpack gear & material hopper: the material can be unpack
by the gear on the net cover, and be even poured into the tank.
7. Quick snap: easy to fix the material hopper and the cart.
8. 5.5KW motor & retarder: to drive the twister for material transportation.
9. Stirrer tank: quick and even mixing material.
10. Water inlet: lead water into the machine from outside.
11. Spinning Form Twister & Screw Pump: the material will be transport to the outlet by
the screw pump after the quick and even mixing by twister.
12. Pressure controller: to adjust the pressure of the mortar pipe to avoid the suddenness
13. Mortar pipe connector: very easy to connect with the machine.
The model of DP-N6 series Cement Mortar Sprayers as follows:
Technical Data:
Voltage/Frequency: 380V/50Hz
Motor Power: 4.5/5.5KW two level adjustable, variable speed (lower/high)
Pump Delivery Capacity: 50L/min ( N6M 40L/MIN)
Hopper Volume: 100L
Standard tip size: 14mm*2pcs, 16mm*2pcs
Working Pressure: 30bar
Delivery Height:1-30m
Delivery Distance: 1-60m
Cement Mortar Size: <6mm
Spraying thickness: 2-3cm
(N6M mixing machine capacity: 120L)
(N6M Mixing speed: 52r/min)
G.W.: 290kgs ( N6M 430KGS)
Overall Demension: 214×75×82cm (N6M 235*85*130CM)
Standard Accessories:
Φ32mm*10m mortar pipe 1pc
Φ8mm*20m vent pipe 1pc
Spray gun 1pc
Repair kit 1set
Tip sizes available: 8 / 10 / 12 / 14 / 16 / 20mm.
8 & 10mm: mainly used for fire protection mortar and thin mortar.
12 / 14 / 16 / 20: used for normal mortar spraying.
