Home > Electrical & Electronics > Electric Motor > Stepper Motor > Shade Pole Motor Rotor

Shade Pole Motor Rotor

US$ 1 - 10 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Taiwan, China

Brand Name:

Model Number:

Industrial Motor

Contact Supplier Request Quote Chat Now

Tay Guei Industry Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Taichung Port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Taiwan, China

Brand Name TG

Model Number Industrial Motor

Shade Pole motor rotor

Product Description

shade pole motor stator

A. Most type of stators and rotors are using interlock.
B. All material are from China Steel
C. Manufacture stamping
D. Made in Taiwan

AC Stator & Rotor

Stator(mm)	Slot	Rotor(mm)	Slot	width	shaft hole
190	36T	140	44T/28T	184W	32,35,38,42
180	36T	110	44T/28T	168W	22,25,30,38
160	36T	100	44T	157W	20,25,27,32
160	36T	96	44T	149W	20,22,25,27
160	36T	95	44T/28T	158W	20,22,25,27,31.85
160	32T	95	44T	145W	20,25,31.85
160	24T	88	18T	159W	20,25,27,28,32
160	24T	80	16T/34T	149W	15,17,20,22,25
140	36T	85	44T/28T	135W	20,22
140	36T	85	44T	130W	15.7,15,17,20,22,30
140	32T	85	44T	130W	17,20,22
140	36T	80	44T	135W	15,17,20,22,30
140	24T	70	34T	130W	20,22,25,27
125	36T	75	44T	123W	16,18,20,22
125	32T	75	44T	120W	18,20
121.7	4T	67.3	44T	124W	12.7
114	24T	56	28T	114W	12,17,20
114	24T	55	29T	112.5W
111	24T	67	44T	104W	10,12,12.7,16
110	36T	70	44T	107W	14,16,18
110	24T	65	34T	100W	10,12,14,16
108	24T	70	34T	108W	12,12.7
100	24T	53	22T	95W	8,10,12,15
90	18T	48	23T	89.5W	11.5,12.7
90	18T	48	23T	82W	8,10
90	24T	47	18T	88W	8.03 , 11.6, 12, 14,16
82	16T	44/46	22T	75W	8,10
75	16T	44/46	22T	75W	8,10
66.4	16T	46	22T	75W	8,10

Packaging & Shipping

Paper box or wooden box. Shipping by vessel

Company Information

COMPANY INTRODUCTION

Tay Guei Industry Co., LTD & Chuan Den Precision Co., LTD. established in 1984, having been committed to the most professional operations of silicon steel sheet lamination pressing. At present, our products are divided into two major categories:”STANDARD” and “CUSTOMIZED” products which are widely used in the various types of AC/DC motor products, such as desk/stand fans, ceiling fans, pumps, industrial motors…ETC. Furtherm ore, we developed the silicon steel sheet lamination in 2011 which is conformed to HIGH EFFIENCY MOTOR PRODUCTS of IEC and IE2, IE3 of NEMA and believed to meet with the requirement of consequent high-efficiency ERA.In addition, in order to provide faster service to satisfy the growing demand, we setup Chuan Den Precision Co. LTD. at Dongguan, China in 1990.

Currently, our plant in Taiwan covers the area location of 5,500 square meter and 30,000 square meter in China. The annual output of both plants exceeds more than 50,000 tons. The main material we used comes from Taiwan State-Owned Enterprise, China Steel Corporation, so that we may provide the most special price and highest quality for you. Our customers are included all over the world and we have always followed the most professional QC management and outstanding Technology to serve customers for best achievement.

We sincerely hope that you may grant us an opportunity for us to create the long-lasting and beautiful future for you.
