Home > Electrical & Electronics > Oscillator > 26MHz TCXO 2520 High End GPS Special Crystal Piezoelectronic Quartz Crystal Oscillator
26MHz TCXO 2520 High End GPS Special Crystal Piezoelectronic Quartz Crystal Oscillator
US$ 0.19 - 0.2
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
YL
Model Number:
TCXO 2520
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen/Hongkong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Original Tcxo 20mhz Automatic Electronics for Wireless 3225 Dongguan TechnologyUS$ 0.25 - 0.25MOQ: 1000 Pieces -
Crystal Tcxo Oscillator 28.672mhz Frequency Oscillator 3225US$ 0.25 - 0.25MOQ: 1000 Pieces
-
80mhz Tcxo Smd Crystal Tcxo 2.5*2.0mm ROHSUS$ 0.25 - 0.25MOQ: 1000 Pieces
-
2520 Tcxo 30 Mhz Quartz Crystal Oscillator ManufacturerUS$ 0.25 - 0.25MOQ: 1000 Pieces
-
Tcxo 20mhz Frequency Controlled Oscillator for Wifi 2520US$ 0.19 - 0.2MOQ: 1000 Pieces
Place of Origin
Guangdong, China
Brand Name
YL
Model Number
TCXO 2520
Package Type
Surface Mount
Nominal Frequency
3.5Mhz ~ 80Mhz
Frequency Tolerance
20ppm
Load Capacitance
15pF
Operating Temperature
-40~85
Supply Voltage
3.3V/5.0V
Dimensions
2.5*2.0mm
26MHz TCXO 2520 high end GPS special crystal
Application
Radio communication, audio-visual equipment, office automation equipment, consumer product,etc
Product Description
Dimension&land pattern(unit:mm)
Specification
| Parameters | For Cellular | For GPS | Conditions | |||||||
| Output Frequency | 8 ~ 52 MHz | 8 ~ 52 MHz | ||||||||
| Supply Voltage | DC 1.8V to 3.3V | DC 1.8V to 3.3V | ||||||||
| Output Level | 0.8 Vp-p Min | 0.8 Vp-p Min | 10kohm//10pF | |||||||
| Current Consumption | 1.5 mA / 2.0mA Max | 1.5 mA / 2.0mA Max | 10kohm//10pF | |||||||
| Operating Temperature Range | -30~+85℃ | -30~+85℃ | ||||||||
| Storage Temperature Range | -40~+85℃ | -40~+85℃ | ||||||||
| Frequency Stability | ||||||||||
| vs. Temperature | ±2.0 ppm Max | ±0.5 ppm Max | Referenced to 25 °C | |||||||
| vs. Supply Voltage | ±0.2 ppm Max | ±0.2 ppm Max | Supply Voltage ±5% | |||||||
| vs. Load | ±0.2 ppm Max | ±0.2 ppm Max | 10kohm//10pF | |||||||
| vs. Aging | ±1.0 ppm Max | ±1.0 ppm Max | 1 Year | |||||||
| Frequency Tolerance (Initial) | ±1.0 ppm Max | ±1.0 / ±0.5 ppm Max | 25 °C | |||||||
| Frequency Tolerance (After Reflow) | ±1.0 ppm Max | ±1.0 ppm Max | Referenced to 25 °C | |||||||
| AFC-Characteristics | Custom spec. | Custom spec. | ||||||||
| Harmonics | -8 dBc Max | -8 dBc Max | ||||||||
| Frequency Slope | ±0.3 ppm/ °C (design guarantee) |
±0.1 ppm/ °C | -30~+85℃ | |||||||
13.575mhz smd crystal TCXO 2016 original China manufacturer passive and active elecetronic components
SMD process flow
SMD crystal oscillator 7050 piezoelectric quartz crystal with ic 12.000mhz
DIP process flow
SMD crystal oscillator TCXO 3225 piezoelectric quartz crystal with ic 13.000mhz piezo oscillator
Blank process flow
Packaging & Shipping
Company Information
Simple packaged crystal oscillator
Market
SMD crystal oscillator TCXO 3225 piezoelectric quartz crystal with ic 19.2mhz piezo oscillator
Contact Us
Send Inquiry to This Supplier
5Yrs
Business Type
Manufacturer, Trading Company
Year Established
2002
Factory Size
5,000-10,000 square meters
Total Employees
501 - 1000 People
