Product Description
Vital man powered chain hoist with the good quality and competitive price
1. Low own weight, small mounting sizes and small lever force at full load.
2. Asbestos free brake, holding load at any desired height.
3. Top & bottom hooks are fitted with safety latches as standard.
4. For DC type, the load chain can be pulled freely and easily through the hoist in both directions to attach the load or to tension the chain. For safety reason free chains can not be done when the hoist is under load.
5. Short hand lever with rubber grip.
6. Hand lever operates with little effort due to optimal gear ratio.
7. Drop forged steel suspension & load hooks are heat treated and fracture resistant. In case of dangerous overloading or abuse, the hook does not fracture but will slowly yield.
8. The hoist is fitted with high grade alloy load chain.
9. Inspection of lever hoist & manuals.
Model |
HSH-0.25A |
HSH-0.5A |
HSH-0.75A |
HSH-1.5A |
HSH-3A |
HSH-6A |
HSH-9A |
|
Capacity load (t) |
0.25 |
0.5 |
0.75 |
1.5 |
3 |
6 |
9 |
|
Standard lift (m) |
1 |
1 |
1.5 |
1.5 |
1.5 |
1.5 |
1.5 |
|
Test load (t) |
0.375 |
0.75 |
1.125 |
2.25 |
3.75 |
7.5 |
11.25 |
|
Effort to rated capacity (N) |
160 |
240 |
280 |
310 |
320 |
340 |
360 |
|
NO. of load chain |
1 |
1 |
1 |
1 |
1 |
2 |
3 |
|
Diameter of load chain (mm) |
4 |
5 |
6 |
8 |
10 |
10 |
10 |
|
Dimensions (mm) |
a |
95 |
108 |
155 |
180 |
215 |
215 |
215 |
c |
90 |
105 |
135 |
155 |
200 |
200 |
330 |
|
Net weight (KG) |
3.6 |
6 |
6.5 |
11 |
20 |
33 |
43 |
|
Extra weight per meter of extra lift (kg) |
0.3 |
0.5 |
0.8 |
1.4 |
2.2 |
4.4 |
6.6 |
|
