Help Center120W AC DC Power Supply
Related Products
Specifications
1.120W AC DC Power Supply2.High quality and attractive price
3.Over load and short circuit protection
4.No limited MOQ
120W AC DC Power Supply
Product introduction
Full range of input, communication with the flow, over-voltage, short circuit protection function, since the cold heat dissipation, 100% full load test, low price, machine of high quality, reliable quality, 1 year of quality assurance
The input voltage range: 85-264 VAC, 47-63 Hz; 120-370 VDC
Impact current: cold start current
Dc voltage adjustable scope: 10% of the rated output voltage
Overload protection: 115% ~ 150% off current, automatic recovery
Over-voltage protection: output voltage of 115% 135%
Start up, keep time: 300 ms, 50 ms, 80 ms
Sex: input/output voltage between input and the shell: 1.5 KVAC output and the shell KVAC lasted a minute 0.5
Working temperature, humidity:-10 oC-+ 60 oC, 20%-90% RH
Safety standards: complying with CE standard
EMC standards: complying with CE standard
The power to be applicable to the industry, safety monitoring, machine, equipment, medical treatment, electrician, LED billboards, communication, and so on! Extensive use!
Max output wattage |
120W |
|||
|
Input |
Voltage |
90-132VAC or 180-260VAC (selectable by switch) |
||
Frequency(HZ |
50-60HZ |
|||
Current(Full load) |
2.5A max (115VAC) 1.6A max (230VAC) |
|||
Inrush Current |
<60AMAX (115VAC) /60Amax (230VAC) |
|||
Leakage Current |
<3.5mA /240VAC |
|||
|
Output |
Voltage |
5VDC |
12VDC |
24VDC |
Voltage Accuracy |
±3% |
±2.5% |
±1.25% |
|
Max. Current |
20 |
10 |
5 |
|
Line Regulation |
±0.5% |
±0.5% |
±0.5% |
|
Load Regulation) |
±1% |
±1% |
±1% |
|
Minimum Load |
0% |
0% |
0% |
|
Typical Efficiency |
78% |
81% |
87% |
|
Adjustable extent of output voltage |
4.5-6.5V DC |
9-15V DC |
22-27V DC |
|
Ripple Noise(max) |
150mV |
150mV |
150mV |
|
Hold-up time |
20 ms min |
|||
Switching Frequency |
30KHZ |
|||
|
Protection |
Over Load |
105-150% rated output power |
||
Protection type: Auto recovery | ||||
Short Circuit |
Protection type: Auto recovery |
|||
Electric Strength |
Input-Output |
1500VAC |
||
Input-FG |
1500VAC |
|||
Output-FG |
1500VAC |
|||
|
Safety EMC
|
Safety Standards |
UI60950 EN60950 |
EMI |
EN55011 class B EN55022 class B |
|
EMS Immunity |
EN55024 EN61000-6-2 |
|
Harmonic Current |
EN61000-3-2 |
