DSHJ-1F Brookfield Rotary Viscometer

DSHJ-1F Brookfield Rotary Viscometer thumbnail-1
DSHJ-1F Brookfield Rotary Viscometer photo-1
US$ 500 - 3,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Dshing
Model Number:
DSHJ-1F
Contact Supplier Request Quote Chat Now
Dshing Instrument Co., Ltd.(Zhuhai)
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Dshing
Model Number DSHJ-1F
Power Electronic
Usage Other, Rotational Viscometer

DSHJ-1F Brookfield Rotary Viscometer



I.Purpose

The instrument is designed and made as per T0625 in the Industry Standard JTJ052 Specification and

Test Methods for Bitumen and Bituminous Mixtures for Highway Engineering,and ASTM D4402. It has a

very wide range of functions. First of all, it is suitable to determine apparent viscosity of highway asphalt

at a temperature from 45 °C to 200 °C as per Brookfield Viscometer Rotation Methods. And then, it can

be used to determine construction temperature for bituminous mixture as per viscosity-temperature curve.

At last also it can be used to determine viscosity of hot melt adhesive, oil grease, paraffin and high polymer.

It can be widely used in cosmetics, food, pharmaceutical, dopes, chemical, and other industries.



II.Technical parameters

1. Relative humidity: not more than 80%.

2. Power supply: AC 220V±10%, 50 Hz;

3. Spindle speed: 0.1~100 RPM continuously adjusted;

4. Measurement error: ± 2% (F•S) (± 3% (F•S) for No.30 spindle);

5. Temperature controlling range: 25°C~200°C;

6. Temperature controlling accuracy: ±0.1°C;

7. Cubage of sample chamber: 20 ml;

8. Spindles: four spindles of No.21, 27, 28 and 29 (No.30 spindle is optional);

9. Ambient temperature: 5°C~35°C (the ambient temperature should be about 5 °C lower than controlling temperature of heater);

10.Measurement range: 25mPa•s~1×10000000mPa•s (If purchase the No.30 spindle, its measurement

range can be extended to 2×10000000mPa•s);
