Hilink 1310/1550 Polarization Insensitive Optical Circulator
Features
High Channel Isolation
Low Insertion Loss
High Return Loss
Low PDL
High Stability and Reliability
Compact in-Line Package
Epoxy Free Optical Patch
Application:
•Optical Fiber Amplifier
•CATV Optical Fiber Link
•Optical Fiber System testing
•Wavelength Add/Drop
•Dispersion Compensation
•Bi-Direction Communication
Optical Circulator Parameter:
Grade |
GRADE P |
GRADE A |
Construction |
Port1 to Port 2, Port2 to Port3 |
|
Operation Wavelength(nm) |
1310/1550/C&L Waveband |
|
Standard Input Loss(23°C) |
0.6 |
0.8 |
Max. Insertion Loss(23°C) |
0.8 |
1 |
Max. Isolation(dB) |
50 |
|
Min. Isolation(dB) |
40 |
|
Directivity(dB) |
50 |
|
PDL(dB) |
0.15 |
|
PMD(ps) |
0.1 |
|
RL(dB) |
50 |
|
Bandwidth(nm) |
+/-30 |
|
Max. Operating Power(mw) |
500 |
|
Operating Temperature(°C) |
0~70 |
|
Storage Temperature(°C) |
-40~85 |
|
Dimension (mm) |
Φ5.5xL50 or 90*20*9.5 |
|
