1x4 DWDM Multiplexer Optical Demux
- 3000 Unit / Units per Month
- Shenzhen
- T/T Credit Card
- ZTE 5928E, RS-5928E, RS-59EC-PWR-AC10, RS-59EC-PWR-DC10, 24 GE RJ45 + 1 expansion card ZTE ZXR10 5928E 5952E 5916E RS-5916E RS-
- ZTE 2952E, RS-2952E-AC, RS-2952E-DC, 48 FE RJ45 4 GE SFP ZTE ZXR10 2952E 2928E 2918E 2910E
- ZTE 3950-28TM, RS-3950-28TM-AC, 24 FE RJ45 + 2 GE SFP + 1 expansion card slot ZTE ZXR10 3950
- ZTE 2950-18TC, RS-2950-18TC-AC, 16 FE RJ45 + 2 GE Combo ZTE ZXR10 2950
- ZTE S2XF48A, 48-port 10GE SFP+ optical interface ZTE ZXR10 8902E 8905E 8908E 8912E RS-8902E RS-8905E RS-8908E RS-8912E
- ZTE 5250-28PM-H, RS-5250-28PM-H, 20 GE RJ45 (POE/POE+) + 4 GE Combo ports + 1 expansion card ZTE ZXR10 5250
Product Details
Place of Origin: | Guangdong, China | Brand Name: | Haili | Model Number: | HL-DWDW-Mux Demux-xxxx |
Product Description
100GHz DWDM Mux/Demux Module
1x4 DWDM Multiplexer Optical Demux
100GHz DWDM (Dense Wavelength Division Multiplexer) Mux/Demux Module offers high stable and reliable bandwidth in a cost-effective and small package. DWDM Mux/Demux ITU Wavelength provides the ability to consolidate your services over a single connection, whether voice, data, or Internet. Use fiber wavelength is unrestricted, allowing for increased control and scalability.
Features:
C Band
2-44 channels DWDM Mux/Demux (CH17-CH61)
Channel spacing: 0.8nm(100GHz Grid)
Com port is simplex
Protocol transparent (10Mbps to 100Gbps)
Low insertion loss
Excellent channel isolation
Epoxy-free optical path
Compliant to G.657A1 standard
ISO 9001 manufacturing facility
Wide Operating Temperature: -40~+85℃
Applications:
Channel Add/Drop
DWDM Network
Wavelength Routing
Fiber Optical Amplifier
CATV System
Compliance:
Telcordia GR-1209-CORE-2001
Telcordia GR-1221-CORE-1999
ITU-T G.694.1
RoHS
1xN DWDM Mux/Demux Module
Parameters |
| ||||||
Channel Space (GHz) | 100 | 200 | |||||
Channel Number | 1*4 | 1*8 | 1*16 | 1*4 | 1*8 | 1*16 | |
Center Wavelength (nm) | ITU Grid | ||||||
Center Wavelength Accuracy (nm) | ± 0.05 | ± 0.1 | |||||
Channel Passband (@-0.5dB) (nm) | 0.22 | 0.5 | |||||
Fiber Type | SMF-28e with 900um loose tube or customer specified | ||||||
IL (dB) | 1 | 1.5 | 2.2 | 1.7 | 2.9 | 3.8 | |
Passband Ripple (dB) | 0.35 | 0.4 | 0.5 | 0.35 | 0.4 | 0.5 | |
Isolation (dB) | Adjacent Channel | 25 | 28 | ||||
Non-Adjacent Channel | 40 | ||||||
PDL (dB) | 0.2 | ||||||
PMD (ps) | 0.1 | ||||||
RL (dB) | 45 | ||||||
Directivity (dB) | 50 | ||||||
Maximum Optical Power (mw) | 300 | ||||||
Operating Temperature (°C) | -40~85 | ||||||
Storage Temperature (°C) | -40~85 | ||||||
BOX Package (mm) | 100*80*10 or 140*115*18 | ||||||
LGX Package | 1U,2U | ||||||
19’’ Rack mount Package | 1U |
2~44Channels available.
Com port: simplex or duplex.
Fiber connector: LC/SC or other.
Package: ABS plastic box, LGX metal cassette box, 19inch rack mount.
DWDM Solutions and DWDM SFP/XFP.
Min.Order Quantity: 1pcs is also okay for sample to satisfy your need.
OEM/ODM is acceptable, so tell us your requirements.
Some solutions example:
SFP compatible Brand: Cisco, Huawei, Ciena, H3C, HP, Extreme, Foundry, Brocade, D-link, Alcatel, Riverstone, Enterasys, Netgear, Nortel, Juniper, Ruijie, Zyxel, etc.
Shipment & Payment
1. International Express: DHL, Fedex, UPS, EMS, UPS, TNT and etc.
2. Payment: T/T, Western Union, Paypal and so on.
Guarantee:
›& Brand new.
›& OEM/ODM is available.
›& 100% through quality test and aging test.
›& 3 years warranty (From the date of shipment).
Technician support:
We support technical guide to solve malfunction or substitute components, and provide the project of related networking configuration.
After-sales service
We have after service for 24 hours, promises to supply technical service or guide in anytime.
Our co-workers will be response clients's requirement in 12 hours after emergency happened.
Packing Details: Static bag, Plastic PVC Pack, Retail box, Technical box, or customized.
Company Informations:
Shenzhen Haili Link Technology Co., Ltd. which is specialized in manufacturing and marketing fiber optic products, was founded in 2007.
RoHS, ISO&CE cerificated, we are golden supplier which specializes in this field 10 years with superior quality, competitive price and good solution.
Our core competencies are fiber optics of CFP, QSFP28, QSFP SR4&LR4, CWDM SFP/XFP/X2, DWDM SFP/XFP/X2, solutions of DWDM, CWDM, WDM, MPO, AAWG, etc.
We have an independent Research&Development Department with 8 skillful engineers, with some advanced equipments and devices, such as cisco switch and routers, for further detailed test and procedure.
We also have related optical products and good solutions to satisfy customers' requirements.
Any requirements about CWDM/DWDM Mux/Demux Module, CWDM/DWDM/BiDi SFP/XFP, Xenpak/X2, FWDM and so on.
Send me an inquiry with your requirements directly or add my skype (hilink02) for further information.
It is warmly welcomed if you share the ideas (solutions) with us.
