Specifications
fc fiber optic patch cord1. ROHS compliant
2. Superior Performance Testing
3. Low insertion loss
Low insertion loss SC-SC/SM/ sc optical fiber patch cord 3m
Mini-LC patch cords are designed to provide flexible interconnection
between specialist high density equipment and patch panels, particularly
for use in Storage Area Networks.
1. Conform to IEC, EIA-TIA, and Telcordia performance requirements
2. Available in different fibre types
3. Available with LC and SC connectors
4. Available in standard and custom lengths
5. RoHS, REACH and SvHC compliant
Description |
SM(PC) |
SM(UPC) |
SM(APC) |
MM(PC) |
Insertion loss |
≤0.3dB |
≤0.3dB |
≤0.3dB |
≤0.3dB |
Return Loss |
≥45dB |
≥ 55dB |
≥65dB |
≥35dB |
Repeatability |
<DIV align=center>≤0.1dB</DIV> | |||
| <DIV align=center>Durability</DIV> | <0.2dB typical change,1000 mating |
|||
Operating Temperature |
- 40 to + 80 |
|||
Housing color |
Blue |
blue |
Green |
grey |
Many of our fiber optic cable assemblies are highly configurable. If you don’t see what you are looking for here, please contact Customer Care freely.
