1-2kg 15A Small Gold Smelting Furnace
Frequency conversion electromagnetic induction heating or induction heating for short is a method for heating metal materials by converting power frequency power supply into that of specific range based on the principle of electromagnetic induction. It is mainly applicable to the metal hot working. heat treatment. welding and melting.
Basic components of induction heating system include induction coil. AC power source and work pieces, Induction coil can be fabricated into different shapes as per different heated objects. The coil is connected with the power source providing alternating current for coil. The alternating current possessed by the coil can create an alternating magnetic field passing through the work pieces to produce eddy flow as required by heating.
Power and Technological Characteristics of Gold Smelting Furnace
- Induction heating mainly through the crucible. to precious metal in an instant , then smelting .refining ,casting and other processes.
- For the precious metals: platinum, palladium, rhodium, gold, silver, copper. Steel, gold powder, sands, tin, tin slag ash all these melting point metals.
- A single molten metal quantity:1kg-50kg.a single melting time:2-20 minutes.
- The maximum furnace temperature up to 1500-2000 degrees.
- Commission for the mummer of ash –like powder high up to 97 percent.
Requirements of Cooling Water of Gold Smelting Furnace
| Water feeding temperature | <50°C |
| Pressure | >0.1MPa |
| Flow | 5-20L/min |
| Max. Temperature of discharging water | Can not over 70°C |
| Water quality | Clean soft water |
Advantages of Gold Smelting Furnace
1. Fast heating, wide heating
2. Comprehensive protection
3. Easy installations. Easy operation
4. High effectiveness
5. Small size and light weight
6. Elimination of high voltage
Technical Specifications of Gold Smelting Furnace
Model |
15A |
25A |
35AB |
45AB |
60AB |
80AB |
100AB |
120AB |
Power |
5kw |
5kw |
10kw |
15kw |
25kw |
35kw |
45kw |
70kw |
Power Source |
220V |
380V |
380V |
380V |
380V |
380V |
380V |
380V |
Oscillation frequency |
20-50KHZ |
1-10KHZ |
||||||
|
Batch melting capacity for gold, copper, silver |
1~2kg |
1~4kg |
1~8kg |
1~10kg |
~20kg |
~30kg |
~50kg |
80~100kg |
Batch melting time |
≤3Min |
≤5Min |
≤5Min |
≤20Min |
≤20Min |
≤30Min |
≤40Min |
≤50Min |
Types available of Gold Smelting Furnace
There are mainly 3 types of Gold Melting Furnace, they are:
- Portable type Gold Smelting Furnace
- Cabinet type Gold Smelting Furnace
-
Tilting type Gold Smelting Furnace
| Cabinet type melting furnace | Portable type melting furnace |
| Models 15A to 45AB are cabinet and portable type for option | |
| Auto tilting type melting furnace | |
| Models 60AB to 120AB are tilting type with larger capacity |
Each set of melting furnace is configured with one set of crucible and one crucible tongs.
The cooling water pump for cabinet type furnace has been included in the configuration.
But the portable type furnace from 25A to 120AB do not include the pump in the factory configuration.
Gold Smelting Furnace Gold Smelting Furnace Gold Smelting Furnace
The melting furnace is usually packed in plywood boxex before shipment.
Gold Smelting Furnace Gold Smelting Furnace Gold Smelting Furnace
Perry Mining will offer you the turnkey solution for your ore mining professionally. Just trust us and let us do it for you!
Gold Smelting Furnace Gold Smelting Furnace Gold Smelting Furnace
Jiangxi Perry Mining Machinery Manufacturing Co., Ltd, professional in mining equipment manufacturing, has more than 25 years' manufacturing experiences. Our equipment had been exported to more than 50 foreign countries.
|
Jiangxi Perry Mining Machinery Manufacturing Co., Ltd is a company who specially supplies mining equipment for export, layout design, plant installation & debugging, and technical support. With more than 25 years' manufacturing experiences, our customers and services have covered more than 50 countries all over the world.
Main product: complete gold washing plant, shaking table, gold concentrator, jig, spiral chute, trommel screen, ore washing machine, crushers, grinding mills, screening equipment, and so on. |
