Overview:

ACR35 NFC MobileMate Card Reader is the perfect tool that you can use with your mobile device. Combining two card technologies into one, it provides its user the flexibility to use magnetic stripe cards and smart cards without the additional cost.

With a rechargeable Lithium-ion battery and standard 3.5 mm audio jack interface, the ACR35 NFC Mobile Mate can seamlessly extend the usefulness of any mobile device. It delivers NFC reader functionality and mobility, which allows you to use NFC and contactless applications, even for mobile readers without built-in NFC functionality.

ACR35 NFC Mobile Mate uses AES-128 encryption algorithm and DUKPT Key Management system to secure your data.

Portable. Modern. Versatile. Compact. ACR35 NFC MobileaMate Card Reader is a handy and lightweight card reader that is perfect for users who wish to transact securely while on the go.

Features:

• Ø  3.5mm Audio Jack Interface
• Ø  Powered by a Lithium-ion battery (rechargeable through PC-linked mode)
• Ø  Smart Card Reader:

n  Built-in antenna for contactless tag access, with reading distance of up to 50mm (depending on tag type)

n  Supports ISO 14443 Part 4 Type A and B cards

n

n  Supports FeliCa

n  Supports ISO 18092 Tags (NFC Tags)*

n  Built-in anti-collision feature

n  NFC Support:

u  Card reader/writer mode

• Ø  Magnetic Stripe Card Reader:

n  Reads up to two tracks of card data (Track 1 / Track 2)

n  Capable of bidirectional reading

n  Supports AES128 encryption algorithm

n  Supports DUKPT Key Management System

n  Supports ISO 7810 / 7811 magnetic cards

n  Supports Hi-Coercivity and Low-Coercivity magnetic cards

n  Support JIS1 and JIS2

Applications:

• Ø  Mobile Banking & Payment
• Ø  e-Healthcare
• Ø  e-Purse & Loyalty



Tech Specs:

Dimensions	60.0mm (L) x 45.0mm (W) x 13.3mm (H)
Interface	3.5mm 4-pole audio jack
Operating Distance	Up to 50mm (depending on the tag type)
Power	Lithium-ion battery (rechargeable through USB)
Supply Voltage	3.2 to 3.7 V DC
Supply Current	85 mA
Operating Temperature	0-50°C
Card Swipe Speed	Max. 10 IPS (inches per second)
Card Swipe Cycles	Min. 500,000
Magnetic Stripe Card Support	ISO7810 / ISO7811 cards Hi-coercivity and Low-coercivity cards JIS1 and JIS2 cards
Smart Card Interface Support	ISO 14443 Part 4 Type A and B cards FeliCa ISO 18092 Tags (NFC Tags) (except Topaz type)
Compliance / Certifications	ISO14443, ISO/IEC 18092, CE, FCC, VCCI, RoHS 2, REACH
Operating System Support	Android™ 2.0 and above iOS 5.0 and above
