SSR/ Solid State Relay Ssr/relay 12v

SSR/ solid stater relay

Brief introduction:

 Solid state relay  is a non-contact electronic switch with isolation function is a non-contact electronic switch , This product is input power is small, high sensitivity, small control power, good electromagnetic compatibility, low noise and high working frequency, etc.

    Solid state relay currently has been widely used in computer peripheral interface system, air-conditioning, electric heating equipment, temperature control, motor control, numerical control machine, remote control systems, industrial automation device; Lights, dimmer, flasher, lighting, stage lighting control system; Instruments and meters, medical equipment, copiers, automatic washing machines; Automatic fire protection and security systems

Model:SDM(100A-600A)

1.Load voltage: 48-400VDC 48-1000VDC
2.Max Load Current:100A 150A 200A 300A 400A 600A

3.Isolation between In& Out: ≥2500VAC

4.Isolation to case: ≥2500VAC

5.Control Voltage: 3-15VDC 15-32VDC

6.Control Current:5mA-30mA(20mA@max input 32VDC)

7.Turn-on Voltage:≤1.5VAC

8.Off-state Leakage:≤1mA

9.Status indicator: In LED and out on LED

10.Operating Temperature:-40~80°C
