Rotary Switch LW26S/Key-lock Type Switches

Rotary Switch LW26S/Key-lock Type Switches thumbnail-1
Rotary Switch LW26S/Key-lock Type Switches photo-1
Negotiable MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
SICO
Model Number:
LW26S
Contact Supplier Request Quote Chat Now
Qingdao SICO Electrical Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name SICO
Model Number LW26S

Please contact Ms.YIN---- yinhebey [at] gmail [dot] com, sikeqd [at] 126 [dot] com. Thank you.



Introduction
LW26S Key-lock type switche are derivatives of LW26 rotary switches.Installed in equipments,which requires a key to lock the switch. It prevents the unauthorized presonnel from mis-operation.
LW26S Key-lock type switches comply with the GB 14048.3 and IEC 60947-3.
Technical parameter

Description
LW26S-10
LW26S-20
LW26S-25
LW26S-32
LW26S-63
Rated working voltage Ue
V
440
440
440
440
440
Rated thermal current Ith
A
10
20
25
32
63
Rated working current Ie

AC-21A A 10 20 25 32 63
AC-22A A 10 20 25 32 63
AC-23A A 7 15 22 30 57
power
P

AC-23A
KW
3
7.5
11
15
30


Dimensions and installation



Description
 Dimensions(mm) Installation(mm)
A C H
L
 E F
G
LW26S-10
 30 28 8.5
71.5
 Φ16.2 18
1.9
LW26S-20
 48 43 15.6
76.5
 Φ22.3 24.1
3.2
LW26S-20
 64 43 15.6
76.5
 Φ22.3 24.1
3.2
LW26S-20
 64 43 15.6
76.5
 Φ30.5 33
4.8
LW26S-25
 48 45.2 15.6
83
 Φ22.3 24.1
3.2
LW26S-25
 64 45.2 15.6
83
 Φ22.3 24.1
3.2
LW26S-25
 64 45.2 15.6
83
 Φ30.5 33
4.8
LW26S-32F
 48 48 15.6
86.5
 Φ22.3 24.1
3.2
LW26S-32F
 64 48 15.6
86.5
 Φ22.3 24.1
3.2
LW26S-32F
 64 48 15.6
86.5
 Φ30.5 33
4.8





Description
 Dimensions(mm) Installation(mm)
A C H
L
 E F
G
LW26S-10
 φ29 28 8.5
71.5
 Φ16.2 18
1.9
LW26S-20
 φ39 43 15.6
76.5
 Φ22.3 24.1
3.2
LW26S-20
 φ39 43 15.6
76.5
 Φ22.3 24.1
3.2
LW26S-20
 φ39 43 15.6
76.5
 Φ30.5 33
4.8
LW26S-25
 φ39 45.2 15.6
83
 Φ22.3 24.1
3.2
LW26S-25
 φ39 45.2 15.6
83
 Φ22.3 24.1
3.2
LW26S-25
 φ39 45.2 15.6
83
 Φ30.5 33
4.8
LW26S-32F
 φ39 45.2 15.6
86.5
 Φ22.3 24.1
3.2
LW26S-32F
 φ39 45.2 15.6
86.5
 Φ22.3 24.1
3.2
LW26S-32F
 φ39 45.2 15.6
86.5
 Φ30.5 33
4.8





Description
Dimensions(mm)
Installation(mm)
A B K C L H S E F G D1 D2 D3
LW26S-20
 48 84 24 43 51.5 32.5
1~4
 36 36 40 Φ8.5 Φ4.5
Φ20
LW26S-25
 48 84 24 45.2 58 32.5
1~4
 36 36 40 Φ8.5 Φ4.5
Φ20
LW26S-32
 64 112 32 58 72 34
1~6
 48 48 48 Φ10 Φ4.5
Φ34
LW26S-32F
 48 84 24 48 61.5 32.5
1~4
 36 36 40 Φ8.5 Φ4.5
Φ20
LW26S-63
 64 112 32 66 79 34
1~6
 48 48 48 Φ10 Φ4.5
Φ34





Description
Dimensions(mm)
Installation(mm)
A B K C L H E F G D1 D2 D3
LW26S-20
 64 126.5 32 43 51.5
34
 48 48 48 Φ10 Φ4.5
Φ34
LW26S-25
 64 126.5 32 45.2 58
34
 48 48 48 Φ10 Φ4.5
Φ34
LW26S-32
 64 126.5 32 58 72
34
 48 48 48 Φ10 Φ4.5
Φ34
LW26S-32F
 64 126.5 32 48 61.5
34
 48 48 48 Φ10 Φ4.5
Φ34
LW26S-63
 64 126.5 32 66 79
34
 48 48 48 Φ10 Φ4.5
Φ34
