Help Center9" Inch Cutting Disc for Angle Grinders (230*3.0*22.23mm)
Related Products
-
3mm Thick Metal Cutting Discs 4.5'' InchUS$ 0.11 - 0.175MOQ: 10000 Pieces -
4.5'' Slitting Disc 1.0mm and 1.6mm Thick for Stainless SteelUS$ 0.14 - 0.185MOQ: 10000 Pieces
-
6" Inch Abrasive Copper Cutting DiscUS$ 0.301 - 0.525MOQ: 10000 Pieces
-
9" Inch Sheet Metal Abrasive Discs for CutterUS$ 0.55 - 0.85MOQ: 3000 Pieces
-
Small Cutting Discs for Stainless Steel Size 4" InchUS$ 0.099 - 0.178MOQ: 5000 Pieces
Specifications
1.Made by aluminium oxide2.Sharp,high efficiency
3.Two fiberglass mesh,safety
4.Low consumption
5.Ideal for metal steel cut
Factory Advantages
1.Near to raw materials region,low labor costs,so lower production cost,competitive price,
2.Locate in the center of China,low and almost same transport costs to any China main port,
3.Advanced technique,
4.More than 10 years production experience,
5.Strict quality testing,good after-sale service,
6.ISO9001:2000 certificate,
7.Abundant export experience,
8.Accept OEM brand,
9.Small order is accepted,
10.Free samples to test quality.
Raw Materials
High hardness abrasive:ensure cutting sharp sex
Brown aluminium Oxide
High quality reinforced mesh:ensure the security
High quality adhesive resin:ensure good durable performance
Powder phenolic resin:Good technological efficiency,a smaller forming density,greater abrasives structure.
Product:
| Size(mm) | Size(inch) | Shape | Description(A30#RBF) | Colour | Speed(r.p.m) | Speed(m/s) |
|
230x3.0x22.2
|
9x1/8x7/8 | flat |
1.Material:Aluminium oxide 2.Grit size:30#, 3.Hardness(1):R 4.Bonding agent:resin 5.Reinforced net:Two fiberglass nets,two black papers |
Black | 6600 | 80 |
(1)Generally,please chose reasonable hardness cutting wheel to reduce its attrition wear.These factors can affect the cutting wheel hardness:The amount of resin bond to join,Forming density of abrasive,Sintering temperature and sintering temperature etc.
Feature:
1.First glass aluminium oxide raw material with special material,
2.High quality phenolic resion bond,
3.Two full sheets of fiberglass and two paper sheets for durability and safety,
4.More sharp,work efficiency is high,
5.Smooth curve cutting,comfortable hand feeling,
6.High stability,no vibration and no bouncing when cutting the object,
7.Super cooling cutting-won”t burn workpiece surface
8.Only little dust and noise production,
9.Lowest power consumption,high durability,
Usage:
1)It was used for cutting metal, steel,collared metal, cast steel, grey/green cast iron, spheroidal cast iron, casting and nonferrous metal
2)the industry maybe use this wheel
1.machinery industry,
2.automobile industry,
3.shipbuilding industry,
tallurgy industry,
5.investment castings,
nstruction industry.
Domestic leading molding equipment:ensure the stability of the product performance
The process of testing the quality:
1.Check the cutting disc's appearance:
Whether the cutting disc has attrition on the surface
Whether the cutting disc has concave point on the surface
2.Test the cutting disc's diameter
3.Check the cutting disc's thickness
4.Check the cutting disc's aperture:22.2mm
5.Check the cutting disc's cutting capacity
Cutting site
The workpiece after cutting
Test report
size |
cutting object |
cutoff quantity |
efficiency SEC/cutoff |
After cutting |
Φ230×3.0mm |
5×5×0.3cm |
10 |
10 |
Φ 220mm |
Φ250×2.0mm |
5×5×0.3cm |
20 |
15 |
Φ 245mm |
Φ300×2.5mm |
5×5×0.3cm |
20 |
9 |
Φ 283mm |
Φ350×2.5mm |
5×5×0.3cm |
20 |
7 |
Φ 336mm |
Cautions:
1.Do visually inspect all wheel before mounting for possible damage.
2.Do make sure operating speed of machine, does not exceed speed marked on wheel,its blotter or container.
3.Do check mounting flanges for equal size,relieved as required and correct diameter.
4.Do be make sure work rest is properly adjusted on bench,pedestal and floor stand grinder.
5.Do always use safety guard that covers a mimimum of one-half the abrasive wheel.
6.Do allow newly mounted wheel to turn at operating speed,with guard in place,for at least one minute beforerinding.
7.Do ture off coolant before stopping wheel to avoid creating an out-of-balance condition.
Safety Recommendatio
1.Wear protective goggles;
2.Wear protective gloves;
3.Wear ear protectors;
4.Wear dust respirators;
5.Observe safety recommendations.
Packing:
1.During transport,please load and unload carufully to prevent the crack and shock.Ensure packing without damage.
2.During storage,put the discs horizontally,donot touch the floor directly.
3.Should prevent moisture and direct sunlight,keep the warehouse shady and ventilated.The warehouse's temperature can not be less than 5 degrees
Dimension |
Dimension |
Speed |
Speed |
G.Weight |
Dimension |
Box Qty |
|
Piece/ |
Piece/ |
||||||
100x3.0x16 |
4x1/8x5/8 |
15200 |
80 |
24 |
440x230x205 |
25 |
400 |
115x3.0x22.2 |
41/2x1/8x7/8 |
13300 |
80 |
23 |
380x260x205 |
25 |
300 |
125x3.0x22.2 |
5x1/8x7/8 |
12200 |
80 |
27 |
410x280x205 |
25 |
300 |
150x3.0x22.2 |
6x1/8x7/8 |
10200 |
80 |
26 |
330x330x200 |
25 |
200 |
180x3.0x22.2 |
7x1/8x7/8 |
8500 |
80 |
19 |
390x390x115 |
25 |
100 |
230x3.0x22.2 |
9x1/8x7/8 |
6600 |
80 |
16 |
490x250x110 |
25 |
50 |
