Help Center14" Inch 350x3.0x25.4mm Reinforced Resin Bonded Abrasive Cutting Wheel For Metal/Steel/Iron
Related Products
-
Abrasive Rail Cutting Disc 80m/s With Double Reinforced MeshUS$ 0.95 - 1.68MOQ: 2000 Pieces -
16" Inch Concrete Cutting Wheel With Single MeshUS$ 0.9 - 2.02MOQ: 2000 Pieces
-
100mm Silicon Carbide Cut off Wheel for StoneUS$ 0.112 - 0.215MOQ: 10000 Pieces
-
Type 41 Cutting Discs for Cast Iron ManufacturerUS$ 0.26 - 0.458MOQ: 10000 Pieces
-
9 Inch Cutting Wheel for Asphalt UsageUS$ 0.55 - 0.95MOQ: 10000 Pieces
Specifications
1.Aluminium oxide made2.One or two nets,high strength
3.High efficiency,safety
4.Lower consumption
5.Cutting big metal,iron
Factory Advantages
1.Near to raw materials region,low labor costs,so lower production cost,competitive price,
2.Locate in the center of China,low and almost same transport costs to any China main port,
3.Advanced technique,
4.More than 10 years production experience,
5.Strict quality testing,good after-sale service,
6.ISO9001:2000 certificate,
7.Abundant export experience,
8.Accept OEM brand,
9.Small order is accepted,
10.Free samples to test quality.
Raw Materials
1)High hardness abrasive:ensure sharp cutting
2)High quality reinforced fiberglass net:ensure the security of power 355 cutting machine
3)High quality combined material resin bond:ensure good performance and durable
Powder phenolic resin:Good technological efficiency,a smaller forming density,greater abrasives structure.
Cutting Wheel Details
| Size(mm) | Size(inch) | Shape | Description(A30#QBF) | Colour | Speed(r.p.m) | Speed(m/s) |
|
350x3.0x25.4
|
14x1/8x1 | flat |
1.Material:Aluminium oxide 2.Grit size:30#, 3.Hardness(1):Q 4.Structure number(2): 4 5.Bonding agent:resin 6.Reinforced net:one or two fiberglass nets |
Brown,black | 4400 | 80 |
(1)Generally,please chose reasonable hardness cutting wheel to reduce its attrition wear.These factors can affect the cutting wheel hardness:The amount of resin bond to join,Forming density of abrasive,Sintering temperature and sintering temperature etc.
(2)The structure number should be larger in order to improve the cutting efficiency,but it should not be too large,otherwise it will affect the strength.
Feature:
1.Premium quality material assure high durability;
2.Imported resin bonded makes our wheel stronger;
3.Two reinforced fiberglass nets keep great strength,add cutting safety;
4.Sharp,fast and smooth cutting,high efficiency;
5.Tolerate high temperatures,won't burn the workpiece's surface;
6.High strength and shock resistance,so no vibration and bouncing when cutting workpiece;
7.Low noise generation and low dust production;
8.Possess superior abrasion resistance,low power consumption,durability.
Application:
1.It mainly used for cutting and grooving general metal and steel,such as sheet metal,non-ferrous material, ferrous metals,angle iron,low hardness cast iron,iron rod,sharpening steel,carbon steel,angle steel,steel pipe,steel bar,steel plate,structural steel tubing,cylindrical steel,small solid bare rod and so on.
2.These industries maybe use the wheel
1)Machinery,2)Automobile,3)Shipbuilding,4)Metallurgy,5)Investment castings,6)Construction industry.
Domestic leading molding equipment:ensure the stability of product performance
Checking cutting wheel quality
1.Check cutting wheel's appearance:
Whether cutting wheel has attrition on the surface
Whether cutting wheel has concave point on the surface
2.Check cutting wheel's diameter
3.Check cutting wheel's thickness
4.Check cutting wheel's aperture:25.4mm
5.Check cutting wheel's cutting capacity
Cutting site
The workpiece after cutting
6.The cutting wheel's test report
| Size | Cutting Object | Cutoff Quantity | Efficiency SEC/cutoff | After Cutting Surplus |
| Φ350×3.0mm | 5×5×0.3cm angle iron |
5 | 5 | Φ349mm |
| Φ350×2.0mm | 5×5×0.3cm angle iron |
5 | 7 | Φ347mm |
| Φ300×2.0mm | 5×5×0.3cm angle iron |
5 | 6 | Φ297mm |
1.Do visually inspect all wheel before mounting for possible damage.
2.Do make sure operating speed of machine, does not exceed speed marked on wheel,its blotter or container.
3.Do check mounting flanges for equal size,relieved as required and correct diameter.
4.Do be make sure work rest is properly adjusted on bench,pedestal and floor stand grinder.
5.Do always use safety guard that covers a mimimum of one-half the abrasive wheel.
6.Do allow newly mounted wheel to turn at operating speed,with guard in place,for at least one minute before grinding.
7.Do ture off coolant before stopping wheel to avoid creating an out-of-balance condition.
Safety Recommendations:
1.Wear protective goggles;
2.Wear protective gloves;
3.Wear ear protectors;
4.Wear dust respirators;
5.Observe safety recommendations.
Packing:
We can make cutting wheel from 4" inch to 16"inch
Dimension |
Dimension |
Speed |
Speed |
G.Weight |
Dimension |
Packing pcs/carton |
250x3.0x25.4 |
10x1/8x1 |
6100 |
80 |
10 |
260x90x260 |
25 |
300x2.0x25.4 |
12x5/64x1 |
5100 |
80 |
12 |
310x80x310 |
25 |
300x2.5x25.4 |
12x3/32x1 |
5100 |
80 |
13 |
310x90x310 |
25 |
300x3.0x25.4 |
12x1/8x1 |
5100 |
80 |
14 |
310x90x310 |
25 |
350x2.5x25.4 |
14x3/32x1 |
4400 |
80 |
17 |
360x90x360 |
25 |
350x3.0x25.4 |
14x1/8x1 |
4400 |
80 |
18 |
360x90x360 |
25 |
400x3.0x25.4 |
16x1/8x1 |
3800 |
80 |
24 |
410x90x410 |
25 |
400x3.0x32.0 |
16x1/8x1 1/4 |
3800 |
80 |
23 |
410x90x410 |
25 |
