Help Center9 Inch Cutting Wheel for Asphalt Usage
Related Products
-
T41 Resin Abrasive Cutting Wheel for Natural StonesUS$ 0.1 - 0.16MOQ: 10000 Pieces -
7" Inch Sheet Metal Cutting Wheels for Portable MachineUS$ 0.33 - 0.545MOQ: 2000 Pieces
-
230mm Carbide Sharpening Abrasive Wheel for Granite CuttingUS$ 0.65 - 1.114MOQ: 3000 Pieces
-
400mm Reinforced Resin Cutting Disc for MetalUS$ 0.85 - 1.5MOQ: 2000 Pieces
-
5" Inches Abrasive Cutting Wheel for Roofing TilesUS$ 0.22 - 0.375MOQ: 10000 Pieces
Specifications
1.Silicon carbide made2.High strength and durable
3.Sharp,give clean cut
4.Long service life
5.Used for asphalt,ceramics
Factory Advantages
1.Near to raw materials region,low labor costs,so lower production cost,competitive price,
2.Locate in the center of China,low and almost same transport costs to any China main port,
3.Advanced technique,
4.More than 10 years production experience,
5.Strict quality testing,good after-sale service
6.ISO9001:2000 certificate,
7.Abundant export experience,
8.Accept OEM brand,
9.Small order is accepted,
10.Free samples to test quality.
Raw Materials
High hardness abrasive:ensure cutting sharp sex
High quality adhesive resin:ensure good durable performance
Powder phenolic resin:Good technological efficiency,a smaller forming density,greater abrasives structure.
High quality reinforced net:ensure the product use security
Product:
| Size(mm) | Size(inch) | Shape | Description(C30#TBF) | Colour | Speed(r.p.m) | Speed(m/s) |
|
230x3.0x22.2
|
9x1/8x7/8 | flat |
1.Material:Silicon carbide 2.Grit size:30#, 3.Hardness(1):T 4.Bonding agent:resin 5.Reinforced net:Two fiberglass nets,two black papers |
Black | 6600 | 80 |
(1)Generally,please chose reasonable hardness cutting wheel to reduce its attrition wear.These factors can affect the cutting wheel hardness:The amount of resin bond to join,Forming density of abrasive,Sintering temperature and sintering temperature etc.
Application:
Ideal for cutting
1.Naturaland artificial stone
2.Marble , brick , concrete
3.Granite,ceramics,basalt,asphalt
4.Clay tubes,clinker,slabs,tiles
Feature:
1.Specially treated silicon carbide grain for extended life and fast cut,
2.Imported resin bonded makes our wheel stronger,
3.Two reinforced fiberglass nets keep great strength and add cutting safety,
4.Sharp,fast and smooth cutting,high efficiency,
5.Tolerate high temperatures,won''t burn the workpiece''s surface,
6.Cutting the workpiece without crack,
7.Low noise generation and low dust production,
8.Possess superior abrasion resistance,low power consumption.
Automatic production line:ensure the stability of our products
The process of checking the quality:
1.Check the cutting wheel's thickness
Performance testing site
Cutting capacity: For examples
size |
cutting object |
cutoff quantity |
efficiency SEC/cutoff |
After cutting |
Φ350×3.0mm |
5×5×0.3cm |
5 |
5 |
Φ 349mm |
Φ350×2.5mm |
5×5×0.3cm |
5 |
7 |
Φ 347mm |
Φ300×2.0mm |
5×5×0.3cm |
5 |
6 |
Φ 297mm |
Cautions:
1.Do visually inspect all wheel before mounting for possible damage.
2.Do make sure operating speed of machine, does not exceed speed marked on wheel,its blotter or container.
3.Do check mounting flanges for equal size,relieved as required and correct diameter.
4.Do be make sure work rest is properly adjusted on bench,pedestal and floor stand grinder.
5.Do always use safety guard that covers a mimimum of one-half the abrasive wheel.
6.Do allow newly mounted wheel to turn at operating speed,with guard in place,for at least one minute beforerinding.
7.Do ture off coolant before stopping wheel to avoid creating an out-of-balance condition.
Safety Recommendatio
1.Wear protective goggles;
2.Wear protective gloves;
3.Wear ear protectors;
4.Wear dust respirators;
5.Observe safety recommendations.
Packing:
1.During transport,please load and unload carufully to prevent the crack and shock.Ensure packing without damage.
2.During storage,put the wheels horizontally,donot touch the floor directly.
3.Should prevent moisture and direct sunlight,keep the warehouse shady and ventilated.The warehouse's temperature can not be less than 5 degrees
For Stone/Masonry | ||||||||
MASONRY |
NAME |
SIZE |
SPEC |
MAX OPERATING SPEED |
CARTON Q'TY |
|||
mm |
inch |
m/s |
rpm (min-1) |
|||||
Type-41 |
PER CUT |
100 x 3 x 16 |
4 x 1/8 x 5/8 |
C30T |
80 |
15,200 |
200 |
|
115 x 3 x 22.23 |
4 - 1/2 x 1/8 x 7/8 |
80 |
13,300 |
200 |
||||
125 x 3 x 22.23 |
5 x 1/8 x 7/8 |
12,200 |
200 |
|||||
180 x 3 x 22.23 |
7 x 1/8 x 7/8 |
8,500 |
100 |
|||||
230 x 3 x 22.23 |
9 x 1/8 x 7/8 |
6,600 |
50 |
|||||
Type-42 |
PER CUT |
100 x 3 x 16 |
4 x 1/8 x 5/8 |
C30T |
80 |
15,200 |
200 |
|
115 x 3 x 22.23 |
4 - 1/2 x 1/8 x 7/8 |
80 |
13,300 |
200 |
||||
125 x 3 x 22.23 |
5 x 1/8 x 7/8 |
12,200 |
200 |
|||||
180 x 3 x 22.23 |
7 x 1/8 x 7/8 |
8,500 |
100 |
|||||
230 x 3 x 22.23 |
9 x 1/8 x 7/8 |
6,600 |
50 |
|||||
