Specifications
Newest Wireless Audio Video RC Powered Motor Eagle Glider Transmitter And Receiverrc gilder
Newest
Motor/eagle
Powered rc
Newest Wireless Audio Video RC Powered Motor Eagle Glider Transmitter And Receiver
TX5820V2:
| Transmitter frequency | 32CH |
| Transmitting Power | 2000mW/33dBm |
| Transmitting distance | >8000m(open area) |
| Frequency control | built-in frequency and phase lock loop |
| AV input | analog AV signal input |
| ANT connector | SMA and RPSMA optional |
| power supply | 6-28 volts |
| Current supply | 800mA |
| Size | 68*35.2*27.5mm |
| Net weight | 42g(no cable and antenna) |
Remark:
The transmitter's power input is ranging from 7-12V,however the voltage outpUT from the TX for the camera Is 0.5V,lower than the input power.It's suggested to use lipo battery with mini 500mHA.
Note:antennas must be attched before powering on.
Receiver(RC306):
| Receiving frequency | 5665-5945MHz;8CH |
| Receiving sensitivity | -90dBm |
| Frequency control | built-in frequency and phase lock loop |
| Double lines AV output | analog AV signal output |
| Antenna connector | SMA(Inside the needle) |
| Power supply voltage | 8-12V |
| Dimension | 55*40*15mm(aluminium alloy extrusion shell) |
| Supply current | 100mA |
Remark: The receiver's power input is ranging from 8-12V,dual AV output is supported
Note: the av cable uses 3.5mm plug on the receiver RC305
