B71 FPV Diversity Receiver HD Screen 7-28V For Fishing Bait Boat DJI Octokopter UAV Drone

B71 FPV Diversity Receiver HD Screen 7-28V For Fishing Bait Boat DJI Octokopter UAV Drone thumbnail-1
B71 FPV Diversity Receiver HD Screen 7-28V For Fishing Bait Boat DJI Octokopter UAV Drone photo-1
US$ 1 - 180 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Flysight
Model Number:
RC801 dji drone fpv hd monitor
Contact Supplier Request Quote Chat Now
Shenzhen Aoweishi Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Flysight
Model Number RC801 dji drone fpv hd monitor

Specifications

B71 FPV Diversity Receiver HD Screen 7-28V For Fishing Bait Boat DJI Octokopter UAV Drone
FPV
7-28V
DJI UAV drone
Fishing

FPV Diversity Receiver HD Screen 7-28V For Fishing Bait Boat DJI Octokopter UAV Drone



B71 FPV Diversity Receiver HD Screen 7-28V For Fishing Bait Boat DJI Octokopter UAV Drone

  • 7" HD 1024*600 Screen
  • Two screen options: Matte screen and Mirror/brilliant screen
  • 5 modes support: Diversity/RX1/RX2/AV IN//HDMI mode
  • No "blue screen" .
  • Support Image Zoom Function;
  • Support Fatshark Nextwave&Airwave TX without distorted picture;

  • Support image rotation 180 degree;

  • Built-in Dual Receiver Automatically for best reception Automatic Antenna Switching
  • Dual buffered AV outputs
  • Can receive 2 different channels at the same time
  • Not affect by 2.4GHz R/C Radios
  • Anti-black, anti-blue, anti-flash.
  • AV Receiver with Diversity inputs,AV, HDMI
  • Small, light weight, durable,stylish
  • 32 Channels

B71 FPV Diversity Receiver HD Screen 7-28V For Fishing Bait Boat DJI Octokopter UAV Drone



Display Screen

Diagonal:    7 inch

Resolution: 1024X600

Contrast:    700:1

Luminance: 300cd/m^2



Wireless Receiving

Working frequency:

B71 FPV Diversity Receiver HD Screen 7-28V For Fishing Bait Boat DJI Octokopter UAV Drone

Sensitivity:      -90dBm±1dBm

Channel:          32Channel ( 4 Band X 8 Channel )

Antenna Port:   2 X SMA,50ohm

Diversity receiving: Antenna diversity

TV System: NTSC/PAL

Video output level: 1.0Vp-p Typ,75ohm

Audio output level:1.0Vp-p Typ,10Kohm



AV Port

RX1 AV OUT:      Video,Audio output

RX2 AV OUT:      Video,Audio output

DIV AV OUT:      Diversity receiving, Video,Audio output

AV IN:            Video,Stereo Audio input HDMI IN(A Type) Support

HDMI:            1.3 Digital Input, Support HDMI Audio in

Built-in Microphone:  8Ω/1W X 2



Power Supply

DC IN:  7~28V/ 2A

DC OUT: Output Voltage:DC IN or battery voltage

                Output Current: 1A

Battery:  11.1V/1000mAh(3 series LiPo cells)

Consumption: 12V input:7.8W Dimensions



Dimensions

Main Body:  183X126X19.5mm(not include sun shadow)

Battery:  105X87.5X6.7 mm(not include prominent part)



Weight

Main body:  350 g

Battery:   95 g



Tripod connector: General 1/4 "thread

Working Temperature: -10°C~+65°C





Main Body:B71 FPV Diversity Receiver HD Screen 7-28V For Fishing Bait Boat DJI Octokopter UAV DroneB71 FPV Diversity Receiver HD Screen 7-28V For Fishing Bait Boat DJI Octokopter UAV DroneB71 FPV Diversity Receiver HD Screen 7-28V For Fishing Bait Boat DJI Octokopter UAV Drone

Battery installation:

B71 FPV Diversity Receiver HD Screen 7-28V For Fishing Bait Boat DJI Octokopter UAV Drone

Images:

B71 FPV Diversity Receiver HD Screen 7-28V For Fishing Bait Boat DJI Octokopter UAV DroneB71 FPV Diversity Receiver HD Screen 7-28V For Fishing Bait Boat DJI Octokopter UAV DroneB71 FPV Diversity Receiver HD Screen 7-28V For Fishing Bait Boat DJI Octokopter UAV DroneB71 FPV Diversity Receiver HD Screen 7-28V For Fishing Bait Boat DJI Octokopter UAV Drone

B71 FPV Diversity Receiver HD Screen 7-28V For Fishing Bait Boat DJI Octokopter UAV Drone

B71 FPV Diversity Receiver HD Screen 7-28V For Fishing Bait Boat DJI Octokopter UAV Drone



Packing List;

1*RC801

1*sunshadow

2*antenna

1*battery

AV cable

DC input cable

DC output cable

B71 FPV Diversity Receiver HD Screen 7-28V For Fishing Bait Boat DJI Octokopter UAV Drone
