1/2 gauge valve pressure gauge valve
Product Description
1. Specs
Maximum working pressures:
GV1 up to 6000 psig (414 bar)
GV2 up to 10000 psig (688 bar)
Working temperature:
PTFE packing: from -65℉ to 450℉ (-54℃ to 232)
Graphite packing: from -65℉ to 1200℉ (-54℃ to 649℃)
Non-rotating lower stem, ball tip designs
Safety back seating seals in fully open position
Rolled spindle operating threads
Lubricant for stem thread isolated from the media
Bonnet locking pin fitted as standard
Low torque operating T bar handle
Handle of different colors available for option
2. Standard Material of Construction
3. How to Order
4. How to Order
1. Packing
2.Shipping
For small order or urgent order, we normally send the goods by courier.
For big order, the goods can be sent by sea
Our Service
You should make a safe product selection. When selecting products, the total system design must be considered to ensure safe, trouble-free performance, function, material compatibility, adequate ratings, proper installation, operation and maintenance are the responsibilities of the system designer and user. From quote to delivery, we can provide the detailed support you need
1.CAD Drawing
2. P&ID
3. Component selection
4. Bill of material
5. Professional services such as bending and welding
6. Testing to guarantee the system
7. Professional packaging and delivery
Comapny Information
- Passed ISO9001-2000 & 2008
- Supply OEM/ODM Manufacturing.
- Designed and manufactured to intermix and interchange Swagelok ® and major global brands.
Hike Fluid Equipment Co., Ltd. now has more than 100 staff members, 20% of them are professionals who have rich experience in this field. The rich experience in product development we accumulated ensures us to customize products for the practical application needs of customers. We have more than 50 sets of precision CNC lathes, machining centers, slitting machines, cape cars, millings, sawing machines, washing, drying and testing equipment. Inspection center is equipped with a large number of test equipment and calibration standard parts, such as spectrometer, metallurgical microscope, quadratic element, projector, sclerometer, etc. We set up inspection test equipment calibration system and the maintenance management system.
The main products of Hike Fluid Equipment Co., Ltd. include needle valves, ball valves, instrument manifolds, bellows valves, check valves, twin ferrules series tube fittings, instrument pipe fittings, weld fittings and other kinds of instrumentation valves and fittings. We can provide stainless steel, alloy steel, brass, special alloy and carbon steel. The product executive standard of the company is ANSI, ASME, ASTM, API, MSS, ISO, EN, GB, JB, HG, etc.
FAQ
1. What is the acceptable MOQ?
For this pressure gauge valve , our acceptable MOQ is 1pc. Any trial order in small quantity is welcome.
2. What is the Delivery time?
For samples,we usually have them in stock, so the delivery time will be quite short .
For normal order, the delivery time should be in 2 weeks.
3.What is the acceptable payment term?
T/T, Paypal ,Western Union, MoneyGram, L/C, D/A, D/P
1/2 gauge valve pressure gauge valve
