Product Brief:
B601 series intelligent constant pressure water supply controller is suitable for full-automatic operation,with characteristics of high quality, multi-functional, low noise and strong commonality etc.
Power range:
Single phase 220V input,single phase 220V output: 1HP-3HP(0.75KW-2.2KW)
Advantages:
Professional design based on users’ needs, simplicity of operation and suitable for all kinds of applications,;
According to the water condition to supply constant pressure water automatically after parameters were set correctly, without human intervention
Stop running automatically when no water consumption; Alarm automatically when faults occurred;
Switch-over running automatically in the multiple pump system, balance the using life of pumps;
Available for many kinds of input pressure signals;
Can be connected to upper computer through RS485 communication function for centralized monitoring.
Function Characteristics:
Multi-Pump Control:Can realize 1 master and Max.5 auxiliaries combine work
Sleep Function:Sleep down when have no water consumption, to earn a better energy saving
Freeze-Proofing Function:suitable to low temperature area, prevent pump from freezing
Anti-clogging Function:take precaution against pipe clogging and clean the pipe dirt
Power On Restart:Running automatically when power on
Master Fault Shift Automatically:keep on working when the master break down
Alternate Running:balance every pump’s running time, prolong service life of the whole unit machine
Day-Part Function:3 independent day-part control, up to 7 day-part achieved when define separated
Two Running Mode:synchronous control mode, master-slave control mode
Terminal Control Mode:Terminal Run/Stop,Manual/Auto Control,Electronic Contact Gauge Control
Various of water supply Fault Alarm Function: High-Pressure, Low-Pressure, Low-Level, Transducer Error etc.
As many as 22 kinds of fault protection function: Over-Current, Over-Voltage, Low-Voltage, Phase-Failure, Over-Load etc.
