Help CenterPortable Trapezoidal Rollforming Machine
Related Products
-
Double Decker Roof Roll Forming MachineUS$ 37,000 - 60,000MOQ: 1 Set -
Double Decker Roof Roll Forming MachineUS$ 37,000 - 60,000MOQ: 1 Set
-
8 M Length Automatic Folder MachineUS$ 40,000 - 40,000MOQ: 1 Set
-
Guard Rail Roll Forming MachineUS$ 65,000 - 80,000MOQ: 1 Set
-
Metcoppo Step Tile Rollforming MachineUS$ 60,000 - 70,000MOQ: 1 Set
Specifications
Fully portable trapezoidal rollforming machine1-Technical specifications :
- Electric requirement : 380V/3ph/50Hz
- Hydraulic motor power : 7.5 KW
- Weight of machine : 8 tones
- Dimension : L= 8.5 m; W= 1.6 m; H= 1.8 m
- Roll forming speed : 15m/min
- Max .thickness of material: 0.25 - 0.7mm
- Material Yield Strength : 550 Mpa
- Tolerance of length : +/- 1.5mm
- PLC& Touch panel : SIEMENS (Germany)
- O.D of shaft : 75mm, the material is S45C
- Encoder 360 ppr : KUBLER(Germany)
- Hydraulic system : YUKEN(Japan)
- Electric motor : SIEMENS (Germany)/Mitsubishi( Japan)
-The chassis of machine made from medium duty welded steel I 400 steel and the frame is heavy duty welded box construction.
2-Features :
- Inter-convert automatically levels of speed when stop and start.
- Control system of machine : Stop to cut with digital length, position and bath ,multi orders by PLC and Siemens Touch panel (999 programs).
- Signal feedback from encoder showing current length of product compare with range
- Before finishing each order has alert to pre-cut
- The rollers made of S45C base material solid form CNC precision machined , through hardened with hard chrome finish get hardness 50HRC.
- Pre-cut, profile cut powered by stationary hydraulic : The cutting dies made of SKD 11 base material solid form CNC wire cutting machined , through hardened get hardness 60HRC.
- Emergency stopping system to safe user.
-The machine is equipped with air cooling system allows the machine working continuously from 12 to 16 hours per day.
- A synchronous un coiler speed with roll forming speed
