Specifications
300Mbps SFP routerChipset: Ralink 3052
Peak throughput: 300Mbps
4LAN ports, 1SFP port 2* 5dBi antenna
8M Flash, 32M RAM
300Mbps SFP Ralink 3052 OpenWrt Wireless Router
Mode: WD-8310A
300Mbps Wireless Openwrt Router + 1 SFP + 4 LAN port
8MB FLASH +32 MB SDRAM
The 802.11n wireless router is compatible with IEEE802.11n standard, which supports data rate up to 300 Mbps in 2.4 GHz band.
The WD-8301A is a new design, it has a 10/100M SFP port, and applied to the optical fiber to home network environment. and combined wired/wireless network connection device integrated with internet-sharing router and 4-port switch. It is 802.11b/g/n technology and bring up to 300Mbps transmit rates .It helps user to set up a wired or wireless network, and lets your computers share a high-speed DSL or Cable Internet connection, data files and other resources, such as printers and hard disk storage space.
The WD-8310A provides a handy feature that allows users to almost instantly setup their security simply by pressing the WPS button on the wireless router and the WPS button on the wireless adapter The AUTO-RUN CD can help novice user setup the router step by step to complete the Internet connection, wireless network settings and security configurations.
- 300M Wireless Router with Extended Range
- Built-in 4-port 10/100M Switch
- Supports far-distance transmission, 200 meters indoor, 400 meters outdoor (depends on the environments around)
- Supports remote/local Web management and TFTP upgrade
- Supports PPPoE, Dynamic IP, Static IP, L2TP, BigPond
- Cable Internet Access, 802.1X, with 5 dBi Detachable Antenna
- Supports WDS wireless network extension
- Supports DHCP server/client ,Built-in firewall for anti-attack
- Supports virtual server, DMZ host , SNTP
- Supports QoS, VPN function
- Provide 1 SFP port and 4 LAN ports
- Provide 8MB Flash/32MB RAM
- Support OPEN-WRT
Standards |
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
|
Wireless Signal Rates With Automatic Fallback |
11n: Up to 300Mbps (Dynamic) 11g: Up to 54Mbps (Dynamic) 11b: Up to 11Mbps (Dynamic) |
Frequency Range |
2.4-2.4835GHz |
|
Wireless Transmit Power |
20dBm(EIRP) |
Modulation Type |
DBPSK,DQPSK,CCK, OFDM |
Receiver Sensitivity |
270M: -68dBm@10% PER 135M: -68dBm@10% PER 54M: -68dBm@10% PER 11M: -85dBm@8% PER |
Wireless Security |
64/128 bit WEPWPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES) |
Interface |
4 10/100M LAN Ports and 1 SFP Ports |
Antenna Type |
2*5dBi detachable Antenna |
Power supply |
Input AC110~240V,output DC/12V/1A |
Operating Temperature |
0°C~40°C (32°F~104°F) |
Storage Temperature |
-40°C~70°C (-40°F~158°F) |
Relative Humidity |
10% ~ 90%, non condensation |
Storage Humidity |
5%~95% non-condensing |
Weight |
400g |
Containing Details:
1* 300Mbps openwrt Router
1* 12V/1A Power supply
1* User Manual
2* 5dBi antenna
