802.11n 300Mbps OpenWRT Router / Ralink RT3052 Chipset OpenWRT WiFi Router

Specifications

300Mbps Ralink 3052 Chipset Open WRT Wireless Router
Flash 8M + RAM 32M
SMA 2 dBi Antenna(2T2R)

300Mbps Ralink 3052 Chipset Open WRT Wireless Router(SL-R7203)







The 802.11n wireless router is compatible with IEEE802.11n standard, which supports data rate up to 300 Mbps in 2.4 GHz band.



The SL-R7203 is a combined wired/wireless network connection device integrated with internet-sharing router and 4-port switch. It is 802.11b/g/n technology and bring up to 300Mbps transmit rates .It helps user to set up a wired or wireless network, and lets your computers share a high-speed DSL or Cable Internet connection, data files and other resources, such as printers and hard disk storage space.



The SL-R7203 provides a handy feature that allows users to almost instantly setup their security simply by pressing the WPS button on the wireless router and the WPS button on the wireless adapter The AUTO-RUN CD can help novice user setup the router step by step to complete the Internet connection, wireless network settings and security configurations.







• 300M Wireless Router with Extended Range
• Built-in 4-port 10/100M Switch
• Supports far-distance transmission, 150 meters indoor, 400 meters outdoor (depends on the environments around)
• Supports remote/local Web management and TFTP upgrade
• Supports PPPoE, Dynamic IP, Static IP, L2TP, BigPond
• Cable Internet Access, 802.1X, with 2dBi Detachable Antenna
• Supports WDS wireless network extension
• Supports DHCP server/client ,Built-in firewall for anti-attack
• Supports virtual server, DMZ host , SNTP
• Supports QoS function
• Provide 1WAN port and 4LAN ports
• Provide 8*32 or  16*64 Ram/Flash for optional choose
• Support OPEN-WRT

 Specifications:



Standards	IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Wireless Signal Rates With Automatic Fallback	11n: Up to 300Mbps (Dynamic) 11g: Up to 54Mbps (Dynamic) 11b: Up to 11Mbps (Dynamic)
Frequency Range	2.4-2.4835GHz
Wireless Transmit Power	20dBm(EIRP)
Modulation Type	DBPSK,DQPSK,CCK, OFDM
Receiver Sensitivity	270M: -68dBm@10% PER 135M: -68dBm@10% PER 54M: -68dBm@10% PER 11M: -85dBm@8% PER
Wireless Security	64/128 bit WEPWPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES)
Interface	4 10/100M LAN Ports and 1 10/100M WAN Ports
Antenna Type	2dBidetachable Omni-directional Antenna
Power supply	Input AC100~240V,output DC/12V/1A
Operating Temperature	0°C~40°C (32°F~104°F)
Storage Temperature	-40°C~70°C (-40°F~158°F)
Relative Humidity	10% ~ 90%, non condensation
Storage Humidity	5%~95% non-condensing
Weight	260.5g
Dimensions	130mm×90mm×25mm





OEM service

Packaging contains300Mbps Open WRT Wireless Router(SL-R7203)



1* 300Mbps Router

1* 12V 0.5A Power supply

1* User Manual

2* 2dBi antenna





We areLG, D-Link, Telecom of Russia, Telecom of India, Skyworth, China Netcom and China Telecom’s OEM supplier, and have our own brand WIDEMAC, SKYLINK, TIANHAO, BLUEWAY on the market.
