Specifications
Chipset: Ralink 305014dBi Tablet Directional antenna
802.11N 150Mbps
POE support
Support Router/Bridge/Reptear/Client
Specifications:
2000mw High Power 150M Long Range Wireless Outdoor Router
Support AP / Bridge / Client / Repeater Mode
Support Ralink3050 chipset
Support Openwrt Software
With 14dBi Tablet Directional Antenna
Features:
- 150M Wireless Outdoor CPE / AP
- RT3050 chipset
- 14dBi built-in antenna
- Output power is 1000mw
- Pass CE certification
- Complies with IEEE 802.11b/g/n, wireless speed up to 150Mbps
- High output transmission power and reception sensitivity optimized
- 14dBi dual-polarized directional antennas fit for various environments and boost your signal level
- Weatherproof enclosure and lightning protection terminal integrated
- Supports WISP Mode
- Supports Passive Power over Ethernet
- Support 5kV ESD Protection
- Support 4000V Lightning Protection
- Supports AP Client Router, AP Router and AP operation mode
- Distance Adjustment for long range transmission, up to 50km
- Supports Antenna Alignment
- Supports Layer 2 User Isolation
- Provides throughput monitor indicating the current wireless throughput.
- Supports Ping Watch Dog
- Supports Wireless Speed Test
- Supports SNMP, Remote Management
- Provides WEP, WPA/WPA2, WPA-PSK/WPA2-PSK data security
- Provides external RP-SMA connector for higher gain antenna upgrade
Specification:
Hardware Features | |
WIRELESS STANDARDS |
IEEE 802.11n, IEEE 802.11g |
BUTTON |
Reset Button |
EXTERNAL POWER SUPPLY |
5VDC / 2.0A |
ANTENNA |
14dBi Antenna |
ANTENNA BEAMWIDTH |
Horizontal: 60° Vertical: 30° |
PROTECTION |
5kV ESD Protection, 1000V Lightning Protection Grounding Terminal Integrated |
Software Features | |
FREQUENCY |
2.4-2.4835GHz |
WIRELESS TRANSMIT PPWER |
<20dBm (EIRP, For countries using CE Standards) <27Bm (Peak Output Power, For countries using FCC Standards) |
WIRELESS MODE |
AP Router Mode AP Client Router Mode (WISP Clent) AP/Client/WDS Bridge/Repeater mode |
WIRELESS RANGE |
15km with Integrated Antenna 50km Maximum (High gain directional antenna required) |
SIZE: |
28cm*8.5cm*4cm |
ADVANCED FUNCTIONS |
Up to 60 meters PoE is supported Provides 4-level signal LED indicator |
Others | |
SYSTEM REQUIREMENTS |
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, MAC OS, NetWare, UNIX or Linux. |
ENVIRONMENT |
Operating Temperature: -30°C~70°C (-22°F~158°F) Storage Temperature: -40°C~70°C (-40°F~158°F) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~95% non-condensing |
Packaging contains:
1* 150M Wireless Outdoor CPE / AP
1* Hose Clamp
1* User manual
1* POE power supply
