Specifications
16 Port ethernet switch16port 10/100M Switch
Chipset: Realtek 8316/IC+1717
Case: steel case 13" desktop
16-Port 10/100Mbps Ethernet Switch(TH-1016D)
TH-1016S 16-port 10/100Mbps Ethernet Switch is designed for SOHO (Small Office/Home Office) or workgroup users. Rack-mount size metal case design combined with a safety certified internal power supply make the Switch the most robust product which is very cost-effective for less than 16 users environment. The plug-and-play and auto-negotiation capabilities allow the Switch to auto-detect its link partner (Ethernet adapter, for example) with the best speed. Each port provides full bandwidth (Maximum with 200Mbps in full duplex mode) without a traditional hub´s collision phenomenon downgrading the performance. All ports can be the uplink (cascade) port which is provided to link to another Switch for more ports expansion. Easy read LED indicators are supported for cable installation and normal operation diagnostics. The Switch can be used on desktop and rack-mount.
Features: 16 Port ethernet switch
•Provides 16 10/100Mbps Auto-Negotiation Ethernet LAN ports
•Supports auto MDI/MDIX
•NMA auto-negotiation
•Supports UPnP
•Complies with IEEE 802.3x full-duplex and flow control
•Non-blocking
•Store-and-forward switching
•Integrated 4,000 MAC address table
Specifications: 16 Port ethernet switch
Standards and Protocols |
IEEE802.3, 802.3u, 802.3x, CSMA/CD, TCP/IP |
Basic Function |
Wire-speed Performance |
MAC Address Auto-Learning and Auto-aging | |
IEEE802.3x flow control for Full-Duplex Mode and backpressure for Half-Duplex Mode | |
Backbound Bandwidth |
3.2Gbps |
MAC Address Table |
8k |
Forwarding Rate |
10BASE-T: 14880pps/port |
Transmission Method |
Store-and-Forward |
Ports |
16 10/100Mbps Auto-Negotiation RJ45 ports (Auto MDI/MDIX) |
Network Media |
10Base-T: UTP category 3, 4, 5 cable (maximum 100m) |
LED Indicators |
Power, Link/Act, 100Mbps |
Safety & Emission |
FCC, CE |
Environment |
Operating Temperature: 0°C~40°C (32°F~104°F) |
Power |
100-240VAC, 50/60Hz |
Package Content (what's inside the box)
1 x Th-1016D 16-Port ethernet switch
1 x Power Adapter
1 x Installation CD
1 x User Manual
We are specialize in Network products more than 10 years,we always devoted to provide our client a whole network solution.including modem,router,3G router.WiFi router,High power Wifi adapter,USB wifi adapter,Ethernet switches,Network Switch,Gigabit switch.PCI Lan card and Print sever.
If u are interested in our products,just contact me now!
