Specifications
5 ports Gigabit unmanaged Switch(TH-1005G)5-port Gigabit Switch
Chipset:Realtek 8367
Case: steel case
Meet FCC,CE
Mini size 5 port 10/00/1000M Gigabit Ethernet Switch
Model: TH-1005G
5-port 10/100/1000 M Gigabit Desktop Switch
Description: 5 port Gigabit etherent switch
The TH-1005G 5-Port Gigabit desktop switch provides you an easy way to make the transition to Gigabit Ethernet. Increase the speed of your network server and backbone connections, or make Gigabit to the desktop a reality. Featured with 5 10/100/1000Mbps ports, TH-1005G greatly expands your network capacity, enabling instant large files transferring. So,power users in the home, office, workgroup, or creative production environment can now move large, bandwidth-intensive files faster. Transfer graphics, CGI, CAD, or multimedia files across the network instantly
Features: 5 port Gigabit etherent switch
Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode
Non-blocking switching architecture that forwards and filters packets at full wire-speed for maximum t hroughput
Auto-MDI/MDIX for all ports
Supports MAC address auto-learning and auto-aging
Auto-negotiation ports provide smart integration between 10Mbps, 100Mbps and 1000Mbps hardware
Plug and Play design simplifies installation
Specification: 5 port Gigabit etherent switch
Standards and Protocols |
IEEE802.3, 802.3u, 802.3ab, 802.3x CSMA/CD, TCP/IP |
Chipset |
Realtek 8367 |
Switching Capacity |
10Gbps |
MTBF |
87,600hours (10 years) |
Basic Function |
Wire-speed Performance |
MAC Address Auto-Learning and Auto-aging | |
Complies with IEEE 802.3x full-duplex and flow control | |
Backbound Bandwidth |
16Gbps |
MAC Address Table |
4k |
Forwarding Rate |
10BASE-T: 14880pps/port 100BASE-TX: 148800pps/port 1000BASE-T: 1488000pps/port |
Transmission Method |
Store-and-Forward |
Ports |
510/100/1000Mbps Auto-Negotiation RJ45 ports (Auto MDI/MDIX) |
Network Media |
10Base-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ù STP (maximum 100m) 100Base-Tx: UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100Ù STP (maximum 100m) 1000Base-T: UTP category 5, 5e cable (maximum 100m) |
Environment |
Operating Temperature: 0°C~40°C (32°F~104F) |
LED Indicators |
Power, 10/100M, 1000M |
Size |
44.5*40*34.5cm |
Unit weight |
350g |
AC adaptor |
12V 0.3A |
Package contents:
1* 5 Port 10/100M/1000M Switch
1* 12V 0.5A Power supply
1* User Manual
Pictures:
Application:
