Specifications
mobile wifi hotspots router (WD-705U)Ralink RT3052 Chipset
1Wan + 4port +1USB Port
Meet CE FCC RoHS
2014 Hot mobile wifi hotspots rj45 router (WD-705U)
SKYpe: live:wifi2
Pictures:
Description:
The 300Mbps 3G Ralink RT3052 Wireless Router is compatible with IEEE802.11n standard, which supports data rate up to 300 Mbps in 2.4 GHz band.
The WD-R705U is a 3G broadband networking compatible router, it integrated a 300M wireless access point , a 4port switch, firewall, allows you to quickly set up a 300Mbps wireless network and share a HSDPA/EVDO mobile connection. By plug-in a HSDPA/EVDO USB modem to the router, a Wi-Fi hotspot is established instantly ,allowing users to share an Internet connection somewhere 3G coverage is available. It also can help user to set up a wired or wireless network, and lets your computers share a high-speed DSL or Cable Internet connection.
Features:
300M 3G RT3052 Wireless WiFi Router with Extended Range
Built-in 4-port 10/100M Switch
Supports far-distance transmission, 150 meters indoor, 400 meters outdoor (depends on the environments around)
Compatible with UMTS/HSPA/EVDO USB modems, tested in the field
3G/WAN failover guarantees an 'always-online' Internet connection
Supports PPPoE, Dynamic IP, Static IP, PPTP, L2TP Cable Internet access
SST technology dramatically increases link robustness and stability
CCA technology enhances your signal stablility by automatically avoiding channel conflicts
Wireless security encryption easily at the push of the QSS button
WDS wireless bridge provides seamless bridging to expand your wireless network
Supports QoS function
IP based bandwidth control allows administrators to determine how much bandwidth is allotted to each PC
Specification:
Chipset |
Ralink 3052 |
Standards |
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
|
Wireless Signal Rates With Automatic Fallback |
11n: Up to 300Mbps (Dynamic) 11g: Up to 54Mbps (Dynamic) 11b: Up to 11Mbps (Dynamic) |
Frequency Range |
2.4-2.4835GHz |
|
Wireless Transmit Power |
20dBm(EIRP) |
Modulation Type |
DBPSK,DQPSK,CCK, OFDM |
Receiver Sensitivity |
270M: -68dBm@10% PER 135M: -68dBm@10% PER 54M: -68dBm@10% PER 11M: -85dBm@8% PER |
Wireless Security |
64/128 bit WEPWPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES) |
Interface |
4 10/100M LAN Ports and 1 10/100M WAN Port 1 USB2.0 for UMTS/HSPA/EVDO USB Modem |
Antenna Type |
2dBi detachable Omni-directional Antenna |
Power supply |
Input AC100~240V,output DC/9V/1A |
Operating Temperature |
0°C~40°C (32°F~104°F) |
Storage Temperature |
-40°C~70°C (-40°F~158°F) |
Relative Humidity |
10% ~ 90%, non condensation |
Storage Humidity |
5%~95% non-condensing |
Weight |
260.5g |
Dimensions |
130mm×90mm×25mm |
About us(300M Ralink 3052 Wireless Router):
