Introduction
V2801HE is low density EPON data ONUs designed for fulfilling FTTH request of telecom operators, internet access of SOHO people and renovation request of EPON+EOC infrastructure of cable TV operators. These products are based on the stable and mature Gigabit EPON technology, which have high performance/price ratio, and the technology of layer 2 Ethernet switch as well. They are highly reliable and easy to maintain, with guaranteed QoS. And they are fully compliant to technical regulations such as IEEE802.3ah and technical requirement of EPON Equipment (V2.1 and above version) from China Telecom.
Technical items |
Descriptions |
|
Upstream PON interface |
1 EPON interface, SC single-mode/single-fibre, symmetric 1.25Gbps |
Wavelength |
Tx 1310nm, Rx 1490nm |
Optical interface |
SC/PC connector |
Downstream LAN interface |
1*10/100/1000Mbps auto adaptive Ethernet interface, Full Duplex/Half Duplex, RJ45 connector |
Indicators |
4 indicators, for status of power, PON port and 1 Giga-Ethernet port. |
DC power supply |
+12V@0.5A, external AC-DC power adaptor |
Power consumption |
<5W |
Operating condition |
Operating temp: -5 - +55℃, operating humidity:10-90%(non-condensed) |
Storing condition |
Storing temp: -30 - +60℃, storing humidity:10-90%(non-condensed) |
Device Dimension |
115mm*75mm*28mm (length*width*height) |
CARTON Dimension |
Internal Canton: 185mm*135mm*40mm Package: 425mm*385mm*280mm 40PCS/CTN |
Net weight |
0.24Kg |
