3 phase electric hoist
- 5000 Piece / Pieces per Month
- Shanghai Qingdao Ningbo Shenzhen
- T/T L/C D/P D/A Credit Card PayPal
- Explosion proof electric hoist with curved rail on top of LNG storage tank
- Explosion proof electric hoist with curved rail on top of LNG storage tank
- Low Head Room Wire Rope Electric Hoist
- Stage Chain Hoist Fashion Mini Cool Design
- Wholesale manual hand operated hoist HSZ chain pulley block hoist for factory
- manual door frame pallet stacker
Product Details
Condition: | New | Place of Origin: | Jiangsu, China | Brand Name: | CNRUYI |
Model Number: | CD1/MD1 | Usage: | Construction Hoist | Power Source: | Electric |
Sling Type: | Wire Rope | Maximum Lifting Weight: | 10T | Maximum Lifting Height: | 30m |
Lift Speed: | 8m/min | Certification: | CE ISO, CE/ISO | Warranty: | 1 Year |
After-sales Service Provided: | Overseas third-party support available |
Product Description
3 phase electric hoist
(Taizhou Ruyi Handling Machinery Factory)
Application:
Mainly used for upgrading, migration, handling heavy loads, tanks flip chip bonding, such as installation and removal of various medium-sized concrete, steel, and machinery and equipment for construction and installation company, civil construction and bridge construction of factories and mines , electric power, shipbuilding, automobile manufacturing, construction, highways, bridges, metallurgical, mining, slope tunnels, wells and other infrastructure construction management protection of mechanical equipment.
Introduction:
1. This model electric hoist is a kind of small lifting and hoisting equipment
2.it can be mounted on single beam overhead crane ,gantry cranes, jib type ;also could be installed on a fixed frame
3.electric wire rope hoist as only one normal speed which can satisfy normal application
4.It is widely used in factories, mines, harbors, warehouses, cargo storage area and shops
5.essentially in raising working efficiency and improving working conditions
6. Brake and clutch ensure the safety under any circumstance , no slip under load ;
7. IP44 of hoist frame and brake ensures the optimal corrosion resistance under harsh environment ;
8. Up and down limit switch ensures the safe operation of the hook on the top and bottom position ;
9. Low voltage contactor ensures the safe and reliable operation .
Specification:
Lifting weight | KG | 250 | 500 | 1000 | 2000 | 3000 | 5000 | 10000 | |
Standard lifting height | M | 3-9 | 6-12 | 6-30 | 6-30 | 6-30 | 6-30 | 6-30 | |
Hoisting speed | M/MIN | 8(8/0.8) | 8(8/0.8) | 8(8/0.8) | 8(8/0.8) | 8(8/0.8) | 8(8/0.8) | 7(7/0.7) | |
Running speed | M/MIN | 20(30) | |||||||
Wire rope type | 6×19-3.6 | 6×37-7.4-180 | 6×37-11-155 | 6×37-13-170 | 6×37-15-200 | 6×37-15-200 | |||
H beam orbit model | 16-22b | 16-28b | 20a-32c | 20a-32c | 25a-63c | 28a-63c | |||
Minimum radius of circular orbit | M | 0.8 | 1.5-4 | 2-4 | 2-4 | 2.5-5 | 3.5-9 | ||
Voltage | V | 380 | 380 | 380 | 380 | 380 | 380 | ||
Frequency | HZ | 50 | 50 | 50 | 50 | 50 | 50 | ||
Number of phase | PHASE | 3 | 3 | 3 | 3 | 3 | 3 |
Picture:
Packing:
Why choose us?
1. Real Factory with exporting experience.
More than 10 years of producing material handling equipment and 4 years of exporting experience (former named Vlit Machinery Factory)
2. Price.
Provide factory direct price, will save your cost than buy from third party
3.Excellent quality.
Mainly parts imported from Europe and USA, assembly in China,we can ensure the long time use and safety.
4. Adequate Stock.
We have many kinds of spare parts in stock, we can delivery in 24 hrs.
5. Services.
Professional service team can give powerful support for our products. Engineers have more than 10 years' experience in products and ready to solve all your problems.
6. Innovation.
Technical and management innovation guarantee our quality to be in top position in our industry.
FAQ
Welcome to ask us questions . Don't be shy. We are very professional.
1. How to place an order?
A:Tell us your detail requirements of Europe hot sale battery pallet stacker (Load Capacity? Lifting height etc.) by email or on Trademanager or Skype ,We will send you our offer in 24 hours. If ok, please send us your purchase order, or you can ask us to send you a proforma invoice for your order.
2. What's your Price Terms?
A: We offer FOB ,FCA, CIF, CFR, EXW and DDU price terms.
3. Are you Factory?
A: Yes.
4. Can i place mix order?For example, i need 1 pc Electric Stacker and 1 pc Hand Pallet Truck,can this ok?
A: Yes, of course. You can mix different models as you wish.
5. Can you send the machine to my factory in other city to load the container?
A: Yes, please tell us the detail address, we can arrange to send your factory in time.
6. Are the forklift trucks covered by a warranty?
A: Yes. All our machines carry a full 1 year major parts warranty.
7. Can i get discounts?
A: Yes, For big order, old customer and frequent customers, we give reasonable discounts.
8. How to place an order?
A:Tell us your detail requirements(Load Capacity? Lifting height etc.) by email or on Trademanager or Skype ,We will send you our offer in 24 hours. If ok, please send us your purchase order, or you can ask us to send you a proforma invoice for your order.
9. How could i pay them?
A: We accept Western Union (for parts order, order value less than $1500); T/T(bank transfer,order value at least $1500); L/C (Irrevocable LC at sight, order value at least $10000 )
10. How long could i get my order?
A: Mainly depend on the order quantity
1) Stock products: deliver within 24 hours.
2) If don't have items in stock, then
produce 1 pc, delivery time is 7days;
produce 2~5 pcs, delivery time is 15 days;
produce 6~12 pcs, delivery time is 25 days.
11. Can you add our own logo on the products or use our designs?
A: Yes,of course you can add logo on our products! We provide OEM/ODM service.In addition, we promise your design would protect by law, we won't tell anyone else about this. It's your own copyright.
