RF Coaxial MCX Crimp Male Right Angle Connector
US$ 1.2 - 1.32
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
ZK crimp male connector
Model Number:
MCX-C-JW3A-1 crimp male connector
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI SHENZHEN QINGDAO NINGBO GUANGDONG
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
RF Coaxial MCX Male Right Angle ConnectorUS$ 1.2 - 1.32MOQ: 1 Piece -
RF Coaxial MCX Female PCB Connector Quality ChoiceUS$ 1.2 - 1.32MOQ: 1 Piece
-
RF MCX Male Right Angle Crimp ConnectorUS$ 1.2 - 1.32MOQ: 1 Piece
-
RF Coaxial SMA Female Solder Flange 4 Hole ConnectorUS$ 0.68 - 0.72MOQ: 1 Piece
-
RF SMA Female Solder Flange 4 Hole ConnectorUS$ 0.63 - 0.72MOQ: 1 Piece
Place of Origin
Jiangsu, China
Brand Name
ZK crimp male connector
Model Number
MCX-C-JW3A-1 crimp male connector
Type
MCX
Application
RF
Gender
Male
Product Description
Interface
| According to | IEC60169-36 |
Electrical
| 1 | Characteristic Impedance | 50ohm |
| 2 | Frequency Range | DC-3GHz |
| 3 | VSWR | 1.15 |
| 4 | Dielectric withstanding voltage | ≥750V RMS,50Hz,at sea level |
| 5 | Dielectric Resistance | ≥5000MΩ |
| 6 | Contact Resistance | Outer Contact≤2.5mΩ ;Center Contact≤5.0mΩ |
Mechanical
| 1 | Durability | Mating cycles ≥500 |
Material and plating
|
Description |
Material | Plating |
| 1 | Body | Brass | Au |
| 2 | Insulator | PTFE | – |
| 3 | Center conductor | Phosphor bronze | Au |
Environmental
| 1 | Temperature Range | -40℃~+85℃ |
1.CNC machines ,advanced test equipment
2.All products are suit for ROHS.
3.ISO14001 certificate,ISO9001 certificate
Metal Workshop
Assembly Workshop
Assembly workshop and professional team;
Test Area
Quality: We use the best quality components to ensure the standard of our
product range is of the highest caliber
All products we sold out are strictly selected and tested by our QC department
Packing Area
Certifications
