What is XPS?
XPS (extruded polystyrene) insulation board, is a new insulation material, which is a high quality foam product characterized by smooth skin with a closed-cell structure that looks like a mass of uniform bubbles with common walls between them. There are few, if any, voids between the cells, top and bottom skin.
Features of XPS
Comparing with other traditional insulation materials, such as EPS, PU and Rock wool, XPS is improved in insulation,moistureproof, compressive strength, durability, convenient installation CE Certificate and low cost.
As an ideal material, XPS is widely applied to heat preservation and insulation systems, moistureproof and obstruct systems, with promising potential market.
Main Technical Parameters:
| ITEM | HIM-X-250 | HIM-X-500 | HIM-X-750 | ||||
| Extrude system | 1st Extruder | 2nd Extruder | 1st Extruder | 2nd Extruder | 1st Extruder | 2nd Extruder | |
| Screw diameters | mm | 135 | 150 | 165 | 200 | 75X2 | 200 |
| L/D Radio | L/D | 27:1 | 33:1 | 27:1 | 33:1 | 32:1 | 33:1 |
| Driving Motor Power | kw | 75 | 75 | 90 | 90 | 90 | 110 |
| Heating Power | kw | 110 | 160 | 180 | |||
| Capacity | kg/h | 250~300 | 450~500 | 700~750 | |||
| Product Width | mm | 600 (900) | 600 (900/1200) | 600 (900/1200) | |||
| Product Thickness | mm | 20~100 | 20~100 | 20~100 | |||
| Density | kg/m3 | 33~39 | 33~39 | 33~39 | |||
| Total Power | kw | 280 | 350 | 380 | |||
The Advantages of Our XPS Production Line
1. Economical Investment;
2. Wide Raw Materials Ranges;
3. Environment-friendly;
4.Flexible Capcaities;
5.Rich Experiences;
6.Quality Certificates.
Wood Pallet for Main Extruders; Wooden Case for other parts; Container Loading; Sea-worthy.
Manufacture xps polystyrene production line
Invite customers to test machine inside of factroy
Perform machine testing
Disassemble and pack xps polystyrene production line
Transport
Send engineers to customer’s plant for machine installing, trial-run and training
Carry out other after-sale services.
Since 1998, HiSuccess International Machinery Limited has begun developing the technology and equipments on low-carbon building materials. With the years of professional experience, HiSuccess International Machinery Limited obtained series of technology and technique, formula and formulation, patent and special know-how on Low-carbon Building Materials.
We have exported hundreds of full lines (Plant) to produce Low-carbon Building Materials to many countries which locate in Middle East, Turkey, Western and Eastern Europe, CIS, Russia, Southern and Eastern Asia, South America, Africa and so on.
We installed more than 40 XPS Production Lines abroad. Every XPS Production Line is bringing back considerable profit to the owner. I believe our XPS machinery can satisfy you soon. HiSuccess is one of the best suppliers in the world to provide XPS machinery with top quality, stable performance, reasonable cost and qualified after service.
1.
Q: Are you manufacturer ?
A: Yes, manufacturer of xps polystyrene production line & XPS Foam.
2.
Q:Where are you?
A: Shanghai.
3.
Q: Can we see the running machine?
A: Yes, as we are produce Extruded Polystyrene Foam, you will see the running xps polystyrene production line when visiting us.
