Specifications
options are 0.5-25HZ for low frequencyoptions are 10-500HZ for high frequency
two types of torch cooled mode
For power input of WSME-500 inverter AC/DC pulse TIG welding machine, three-phase 380V±10% power supply is adopted.
For AC and DC TIG modes, with the feature of stepless regulation, the range of base current, pulse current, starting and ending current are all regulated from 20 to 500A.
Besides that, for pulse frequency, the options are 0.5-25HZ for low frequency and 10-500HZ high frequency.
At the same time, there are two types of torch cooled mode, gas cooled mode and water cooled mode. To be more specific, when output current of WSME-500 inverter AC/DC pulse TIG welding machine is lower than 100A, gas cooled mode should be applied, otherwise, water cooled mode is suitable.
INPUT |
Power |
3phase 380V±10% 50HZ |
|
Minimum capacity |
25KVA |
||
MMA |
No-loadVoltage |
75V |
|
Rated Input Current |
28A |
||
Rated Output Current |
400A |
||
DC |
Current Adjusting Range |
20~400A |
|
AC |
Current Adjusting Range |
30~400A |
|
AC frequency |
20-100HZ |
||
AC balance |
30%-70% |
||
DC(PULSE)TIG |
No-load Voltage |
79V |
|
Rated Input Current |
29.7A |
||
Rated Output Current |
500A |
||
Duty Cycle |
60% |
||
Based current adjusting |
20-500A |
||
Pulse current adjusting |
20-500A |
||
Arc starting/end current adjusting |
20-500A |
||
Post flow time |
1-25s |
||
Current Up-slope/Down-slope Time |
0-10s |
||
Pulse Rate |
0.1-0.9 |
||
Pulse Frequency |
0.5-25HZ |
||
DC(PULSE)TIG |
Efficiency |
≥80% |
|
Torch cooled mode |
Gas cooled(<100A) |
||
Arc-starting |
High frequency arc striking |
||
No-load voltage |
79V |
||
Rated Input Current |
29.7A |
||
Rated Output Current |
500A |
||
Duty Cycle |
60% |
||
Based current adjusting |
20-500A |
||
Pulse current adjusting |
20-500A |
||
Arc starting/end current adjusting |
20-500A |
||
AC frequency |
20-100HZ |
||
AC balance |
30%-70% |
||
Pulse With Ratio |
0.1-0.9 |
||
Pulse Frequency |
0.5-25HZ/10-500HZ |
||
Advance gas time |
0.5s |
||
Post flow time |
1-25s |
||
Current Up-slope/Down-slope Time |
0-10s |
||
N.W. |
68KG |
||
Dimension(L×W×H) |
650×350×830 |
||
