newly 12w 20w LED light source AC 110v AC 220V input driverless alu LED PCB Board for ceiling light application
1. Directly connect to 110/220V AC input voltage, without AC/DC conversion;
2. Advanced IC technology, no electrolytic capacitor and transformer lead to longer life;
3. Compact size, flexible and innovative design;
4. High luminous efficiency;
5. High aluminum pcb plate thickness (1.5mm) and high thermal conductivity(1.5);
6. Dimmable, can be matched with dimmer for application;
7. Applicable to down light, ceiling light etc.
8. Professional OEM & ODM service. Different volts input, luminous efficiency, CRI, size and shape etc. can be customized.
Spec
Item Type |
driverless LED Module |
Base Type |
ceiling lamp |
Voltage |
220V |
Beam Angle(°) |
170° |
LED Chip Brand |
San'an |
Number of LED Chip |
78 |
Led Type |
ceiling light |
Average Life (hrs) |
50000 |
Length*Width*Thickness |
110*44*1.5mm |
Color |
White, Warm White |
Shape |
Ring |
Power Tolerance |
10% |
Brand Name |
QIANNENG |
Occasion |
living room |
LED Chip Model |
2835 |
12w 20w LED light source AC 110v AC 220V input driverless alu LED PCB Board
Application of 12w 20w LED light source AC 110v AC 220V input driverless alu LED PCB Board
12w 20w LED light source AC 110v input driverless alu LED PCB Board
1. 50000h life-span Two years warranty;
2. all should apply with alu heat sink;
3. Free samples available, but depends on our qty, not covering shipping cost;
Qianneng electronic co., ltd located in Humen town, which with 17mins distance by high-speed train from Shenzhen & Guangzhou. We are mainly focus on AC220V/110V input aluminum led module with driver on board & PCB design service, which with over 6 years experience in electronic products business, developed from design service only at the beginning.
Our service covers almost all fields of electronic products, including toys, home appliances, machines, stationery, crafts, gifts etc. Most importantly, we offer professional solutions at affordable prices.
1. What LED Chip you use on the driverless LED Module?
- San'an SMD 2835 & 5730
2. What is the life-span of your driverless led module?
- 50000h
3. What is the advantage of your company?
- Manufacturer, Quality is our culture, only focusing on driverless alu led module, ac 220v / 110v input available
4. Does your company offer free samples?
- Free samples available, it depends on qty & items, but not including shipping charges
5. What is your main products?
- driverless alu led module for bulb, for flood light, for high bay light, for tube, for ceiling lamp etc
6. What is the lead time when order placed?
- for our standard item, 2 working days enough
