RunKun200 Q235/ss400 NM Series Coal Conveying Coal Mining Anti Wear Overlay Composite Steel Tube/pipes OD 80-30000 mm

FOB Price

US$ 160 - 500 / Square Meter

8 Square Meters(Min. Order)

Port shanghai
Payment TermsT/T D/P D/A Money Gram PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Thickness	3, 500	Section Shape	Round
Outer Diameter	80 - 3000 mm	Place of Origin	Jiangsu, China
Secondary Or Not	Non-secondary	Application	Other, metallurgy industry
Technique	Hot Rolled	Certification	Other, ISO9000
Surface Treatment	Other, Welding	Special Pipe	Thick Wall Pipe
Alloy Or Not	Is Alloy

Product Description

Specifications

1.Brand name:RK-200
2.Corrosion resistance
3.Heat resistance
4.Impact resistance
5.DIN,GB ISO standard

Detailed product description

Base metal	structure steel,alloy steel
Brand	RK
Color	brown
Diameter	≥80mm(can be customized)
Thickness of wear resistant layer	as customer's requirement
Thickness of pipe wall	5-30mm
Length	can be customized
Hardness	HRC57-62
Standard	DIN,GB
Certificates	ISO9001:2000
Specifications (base layer+wear resistant layer)	5+3,6+3,8+3,5+4,6+4,8+4,10+4,6+5,8+5,10+5, 15+5,20+5,6+6,8+6,10+6,20+6,8+8,10+8,10+10, 15+10,20+10
Model number	steel plate Q235
Grade	first class
Applications	concrete industry,metallurgy,fan industry,coal industry,mining machinery,construction machinery,etc.
Payment terms	L/C,TT,D/P,Western union
Delivery time	15 days after receipt of L/C or advanced payment
Trade terms	FOB,CIF,EXW,etc
Port	shanghai

Products show

Comparsion Chart(based on mild steel)

Grade	Mild pipe	SLS600 Induction hardened steel	Ultra-met steel	Ceramite cast stee
Hardness	120-150BHN	600 BHN	>600BHN	>8Mohs
Max temperature(°F)		450	1250	2195
Impact resistance	Good	Average	Marginal	Poor
Abrasion resistance	Poor	Good	Very good	Excellent
Std size(OD)	Unlimited	3''to26'	10''to40''	4''to24''
Handling&Installation	Excellent	Very good	Very good	Heavier
Fabrication	Unlimited	Some limitaions	Some limitaions	Some limitaions
Emergency repair	Easily patched	Easily patched	Easily patched	Easily patched
Initial cost		3-8 times above mild steel	6-10 times above mild steel	4-8 times above mild steel
Life expectancy		Up to 6 times mild steel	Up to 8 times mild steel	Up to 15 times mild steel
Advantages	Low cost Readily avaliable	A good combination of abrasion&impact resistance	Good wear resistant,moderate temperaure resistance	High wear resistant,good therma shock resistant
Disadvantages	Poor abrasion resistant	No corrosion resistance	Limited length&diamter	Heavier

Characteristic:

1.Abrasion resistance:

20 - 25 times of low carbon steel,

8 times of high manganese steel or stainless steel,

1.5 times of regular high-carbon and high chromium steel.

2.Temperature resistant: regular type < 60°C; high temperature type <1000°C.

3.Impact resistance: wear resistant layer and the base layer are completely metallurgical b -onding, afford strong impact, and do not have to worry about shedding.

4.Processibility: welding, cutting, curling, punching.
