Wear Resistant Alloy Steel Pipe RK200
US$ 160 - 500
MOQ: 1 Piece
Key Specifications
Get Latest Price
Standard:
Grade:
Thickness:
3, 500
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Bimetallic Abrasion Resistant PipeUS$ 160 - 500MOQ: 1 Piece -
Wear Resistant Steel Pipe for Ash CinderUS$ 160 - 500MOQ: 1 Piece
-
Bimetal Anti Abrasion Steel PipeUS$ 160 - 500MOQ: 1 Piece
-
Bimetal Abrasion Resistant Composite PipeUS$ 160 - 500MOQ: 10 Square Meters
-
Chromium Carbide Seamless Steel PipeUS$ 160 - 500MOQ: 1 Piece
Thickness
3, 500
Section Shape
Round
Outer Diameter
100 - 20000 mm
Place of Origin
Jiangsu, China
Secondary Or Not
Non-secondary
Application
Other, Conceret Pipe
Technique
Hot Rolled
Certification
Other, ISO9000
Surface Treatment
Other, Welding
Special Pipe
Thick Wall Pipe
Alloy Or Not
Is Alloy
Specifications
1. Decreasing maintenance cost of equipments2. Reducing energy consumption of mill equipment
3. Improving operation rate
Wear Resistant alloy Steel Pipe RK200 base layer is Q235 metal and it is lined with wear resistant alloy materials. One method of producing the pipes is by inner wall welding machine; the machine can also apply to produce wear resistant pipes with small diameter. The other method of producing the pipe is by curling the wear resistant plate. Our factory can produce any pipe with diameter greater than 80mm.
Comparsion Chart
| Grade | Mild pipe | SLS600 Induction hardened steel | Ultra-melt steel | Ceramite cast steel |
| Hardness | 120-150BHN | 600 BHN | >600BHN | >8Mohs |
| Max temperature(°F) | 450 | 1250 | 2195 | |
| Impact resistance | Good | Average | Marginal | Poor |
| Abrasion resistance | Poor | Good | Very good | Excellent |
| Std size(OD) | Unlimited | 3''to26' | 10''to40'' | 4''to24'' |
| Handling&Installation | Excellent | Very good | Very good | Heavier |
| Fabrication | Unlimited | Some limitaions | Some limitaions | Some limitaions |
| Emergency repair | Easily patched | Easily patched | Easily patched | Easily patched |
| Initial cost | 3-8 times above mild steel | 6-10 times above mild steel | 4-8 times above mild steel | |
| Life expectancy | Up to 6 times mild steel | Up to 8 times mild steel | Up to 15 times mild steel | |
| Advantages |
Low cost Readily avaliable |
A good combination of abrasion&impact resistance | Good wear resistant,moderate temperaure resistance | High wear resistant,good therma shock resistant |
| Disadvantages | Poor abrasion resistant | No corrosion resistance | Limited length&diamter | Heavier |
Specifications
| Name | Wear Resistant alloy Steel Pipe RK200 |
| Brand | RK |
| Color | brown |
| Diameter | as customer's require |
| Thickness of wear resistant layer | as customer's require |
| Thickness of pipe wall | 5-30mm |
| Length | can be customized |
| Hardness | HRC57-62 |
| Standard | DIN,GB |
| Certificates | ISO9001:2000 |
| Specifications (base layer+wear resistant layer) |
5+3,6+3,8+3,5+4,6+4,8+4,10+4,6+5,8+5,10+5, 15+5,20+5,6+6,8+6,10+6,20+6,8+8,10+8,10+10, 15+10,20+10 |
| Model number | steel plate Q235 |
| Grade | first class |
| Applications | concrete industry,metallurgy,fan industry,coal industry,mining machinery,construction machinery,etc. |
| Payment terms | L/C,TT,D/P,Western union |
| Delivery time | 15 days after receipt of L/C or advanced payment |
| Trade terms | FOB,CIF,EXW,etc |
| Port | shanghai |
