Help CenterY3 Low-Voltage Large-power Motor 2 Poles 560kw
Related Products
-
Y3 Low-Voltage Large-power Motor 4 Poles 355kwNegotiableMOQ: 1 Piece -
Y3 Low-Voltage Large-power Motor 4 Poles 400kwNegotiableMOQ: 1 Piece
-
Y3 Low-Voltage Large-power Motor 4 Poles 450kwNegotiableMOQ: 1 Piece
-
Y3 Low-Voltage Large-power Motor 4 Poles 500kwNegotiableMOQ: 1 Piece
-
Y3 Low-Voltage Large-power Motor 4 Poles 560kwNegotiableMOQ: 1 Piece
Specifications
Species: Y3(IP55) Series Low-Voltage Large-power MotorNumber of Stator: Three-Phase
Operating Speed: Constant Speed
Basic Info.
Model NO.: |
Y3 |
Species: |
Y3(IP55) Series Low-Voltage Large-power Motor |
Number of Stator: |
Three-Phase |
Operating Speed: |
Constant Speed |
Application: |
Household and Industry |
Casing Protection: |
Enclosed Type |
Rotor Structure: |
Squirrel-Cage |
Poles: |
2,4,6,8 |
Color: |
as Customer′s Requirement |
Export Markets: |
Global |
Additional Info.
Trademark: |
LUV |
Packing: |
Standard Export Packing |
Standard: |
ISO9001, IEC ,CE |
Origin: |
Liuan, Anhui, China |
Production Capacity: |
10000PCS/Month |
Product Description
1. Ambient temperature: -15º C~+40º C
2. Altitude: Not exceed 1000m
3. Rated voltage: 380V /660V
4. Rated frequency: 50Hz
6. Protection class: IP55
7. Insulation class: F
8. Cooling method: IC411
9. Working duty: S1 (continuous)
10. Basic Installation Method B3 B35 B5
13. Connection method: "Y" connection for 3KV and below, "Δ " connection for 4KV and above.
Y3 Series Three-phase Asynchronous Motors (IP55) are totally enclosed fan-cooled squirrel cage structure motor. It is the first complete series by adopting cool rolled silicon steel sheet in domestic market, with the feature of novel design, nice modeling, low noise, high torque, compact structure, excellent starting performance, easy maintenance etc.
The efficiency conform to regulation of "efficiency limits and energy saving evaluation". The motor's safety and reliability are greatly enhanced depend on F class insulation and IP55 protection class on outer cage.
Mounting dimensions conform to IEC standard.
Advantage:
1. Novel design
2. Excellent starting performance
3. High efficiency
4. Energy-saving
5. High starting torque
6. Low noise
7. Little vibration
8. Safe operation
9. Easy maintenance
