LTMA 2 ton underground forklift working in the underground tunnel
The specifications LTW20F tunnel underground forklift:
Model |
LTW20F |
Overall length (mm) |
5200 |
Overall height(mm) |
1775 |
Overall width(mm) |
2020 |
Lifting Capacity (kg) |
2000 |
Fork lenghth (mm) |
1500 |
Track base(mm) |
1650 |
Wheel base(mm) |
2550 |
Weight(kg) |
5600 |
Minimum ground clearance(mm) |
215 |
Departure angle(°) |
30 |
Car body turn angle(°) |
30 |
Ground position shrink bucket angle(°) |
42.5 |
Maximum lifting height(mm) |
2900 |
Tyre type |
15/70-18 |
Engine |
LR4B3-1A |
Rated engine power(kw) |
60 |
Rated rotate speed(rpm) |
2400 |
Fetures and characteristics of tunnel loader:
1.Power system adopts intercooled turbocharged engine, big power, low emissions.
2. Using technology leader slewing structure, hydraulic steering, rear axle swing compared to traditional forms, lower failure rate, easy to maintain.
3.Walk system uses hydraulic torque converter, power shift transmission, and improve reliability.
4.Operating system adopts pilot control, making the operation more simple work, work more efficiently.
5. Working brake is a spring brake, hydraulic release, and is equipped with an emergency braking system, the brake is safe and reliable.
6.Exhaust system is equipped with imported purifier water filtration system, greatly reducing air pollution.
7.vehicle chassis plate thickening, enhanced vehicle steel bucket shovel blade made of high strength alloy steel, wear resistance to shear, V-type structure, reducing scooping resistance and longer life.
8.Adopt 10.00-20 puncture resistant smooth rubber tires,
9.The machine can be shoveling, loading, transport, unloading one operation, compact structure, convenient operation, high efficiency operation for recovery of mines and tunneling mucking, and workplace and road construction formation, transport of materials and other auxiliary operations.
1). Quality: With CE and ISO certificate, 10 km away from the Xiamen Port, China, 14 years' manufacture's experience specially in loader. LTMA have the customers covers more than 30 districts and zones in the world.
2) Competitive price:we manufacturer’s products are directly exported to buyers without the trading company in China
3).Optional accessories and Customizing:There are some accessories could be chosen by users ,such as engine, transmission,floating forks ,marble slab carrier ,manure fork and grab ,bucket ,fixed platform etc.we can customzing the machines specially for your requirement.
After-sale Service
LTMA always treat after-sale service more important than sale. Nowadays more than 10 agents around the world can supply LTMA professional after-sale service.
All the product of LTMA supplied with one year or 2000 working hours (which occurs first) period quality warranty.
Detail clauses and policies please check our website and product certificate.
1.What's the Certificate do you have?
LTMA workshop meet with the ISO9001:2008 Quality System. All of our products with CE certificate. Some of our products meets the EPA requirements. LTMA never recruit Underage labor.
2. Can you customize and design as the clients' requirement?
LTMA will try its best to meet all kinds of clients' special requirements. However, All the customizing and refit should be implemented safely and scientifically.
The colors can be painted as client's need.
3.How long is the warranty of your products?
Normally 1 year or 2000 working hours whichever occurs first. Details to see the LTMA warranty policy for each model.
4. Can you produce the products labeled with the client's brand?
With the authorization of the brand, we can OEM for our clients.
5. What's the payment terms do you accept?
Normally 30% T/T in advance as deposit, blance paid before shipment.
100% L/C at sight issued by world famous bank with good faith is also available.
6.Delivery time:
Standard configuration products are always in stock. The production period of Customizing products is from 7 days to 90 days.
7, How can you ensure the quality of the products ?
Don’t worry,we joined the trade assurance. If the products have quality problem when you received the goods, Alibaba can return you full payments.
